Tekelec IP7 Secure Gateway Administration Manual page 879

Database Administration Manual - IP7 Secure
Gateway
Number of In-Service Signaling
Links
1
When this threshold is exceeded, a minor alarm (UAM 0116) is generated. When the amount of traffic
on the signaling link falls below this threshold, UAM 0116 is automatically cleared and UAM 0119 is
generated.
The signaling link TPS alarm shows that the linkset TPS is set too low for the linkset or that the IPSG
card's capacity has been exceeded. Setting the signaling link TPS alarm threshold lower than the linkset
TPS alarm threshold can give the user an earlier indication that the linkset TPS is inadequate or that
traffic is not balanced across the links in the linkset.
Changing the MAXSLKTPS or RSVDSLKTPS values for the IPSG M2PA linkset cannot exceed the
maximum total provisioned system TPS shown in the rtrv-tps output. If changing the IPSG M2PA
linkset will exceed the maximum total provisioned system TPS, and the maximum total provisioned
system TPS is 500,000, perform the "Activating the HIPR2 High Rate Mode" feature in the Database
Administration Manual - System Management to enable and turn on the HIPR2 High Rate Mode feature.
When the HIPR2 High Rate Mode feature is enabled and turned on, the maximum total provisioned
system TPS is increased to 750,000. If the maximum total provisioned system TPS is 750,000 or the
maximum total provisioned system TPS is 500,000 and will not be increased, and changing the
MAXSLKTPS or RSVDSLKTPS values for the IPSG M2PA linkset will exceed the maximum total
provisioned system TPS, the MAXSLKTPS or RSVDSLKTPS values for the IPSG M2PA linkset cannot
be changed unless the amount of available TPS is reduced enough to allow the MAXSLKTPS or
RSVDSLKTPS values for the IPSG M2PA linkset to be changed. The available TPS can be reduced by
performing one or more of these actions.
The IP TPS values of some IPGWx linksets have to be changed.
The MAXSLKTPS values of some IPSG linksets (and the RSVDSLKTPS values if necessary) have
to be changed.
Some ATM high-speed signaling links have to be removed.
An IPLIMx card that contains signaling links has to be removed.
This procedure can also be used to change an IPSG M3UA linkset or a non-IPSG linkset to an IPSG
M2PA linkset.
Other Optional Parameters
There are other optional parameters for an IPSG M2PA that can be changed. These parameters are not
required for IPSG M2PA linkset. These parameters are discussed in more detail in the Commands
Manual or in these sections.
These procedures in this manual:
Adding a Mate IPGWx Linkset to another IPGWx Linkset
Removing a Mate IPGWx Linkset from another IPGWx Linkset
Configuring an IPGWx Linkset
These procedures in the Database Administration Manual - SS7
Adding an SS7 Linkset
Changing an SS7 Linkset
910-6278-001 Revision A, January 2012
IPSG M2PA and M3UA Configuration Procedures
Linkset TPS
4000
Signaling Link Fair Share of the
Linkset TPS
4000
879
