Adding a Network Appearance

The network appearance field identifies the SS7 network context for the message, for the purpose of
logically separating the signaling traffic between the SGP (signaling gateway process) and the ASP
(application server process) over a common SCTP (stream control transmission protocol) association.
This field is contained in the DATA, DUNA, DAVA, DRST, DAUD, SCON, and DUPU messages.
The network appearance is provisioned in the database using the ent-na command with these
parameters.
:na – the 32-bit value of the network appearance, from 0 to 4294967295.
:type – the network type of the network appearance, ansi (ANSI), itui (ITU-I), itun (14-bit ITU-N),
itun24 (24-bit ITU-N), ituis (ITU-I Spare), ituns (14-bit ITU-N Spare).
:gc – the specific ITU-N group code associated with the network appearance.
The gc parameter can be specified only with the type=itun or type=ituns parameters.
The gc parameter must be specified with the type=itun or type=ituns parameters if the ITU
Duplicate Point Code feature is on. If the ITU Duplicate Point Code feature is off, the gc parameter
cannot be specified.
The gc parameter value must be shown in the rtrv-spc or rtrv-sid outputs.
The ituis or ituns parameters can be specified only if the ITU National and International Spare
Point Code Support feature is enabled.
1. Display the network appearances in the database with the rtrv-na command. This is an example
of the possible output.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
TYPE GC
ANSI --
ITUN FR 4000000000
ITUN GE 1000000000
Note: If the gc parameter is not being specified in this procedure, continue the procedure with
Step 4.
2. Display the self-identification of the EAGLE 5 ISS using the rtrv-sid command. This is an example
of the possible output.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
PCA
001-001-001
CPCA
002-002-002
002-002-006
004-002-001
CPCA (LNP)
005-005-002
CPCI
1-001-1
910-6278-001 Revision A, January 2012
NA
100
PCI PCN
1-200-6 13482
002-002-003
002-002-007
004-003-003
005-005-004 005-005-005
1-001-2
IPSG M2PA and M3UA Configuration Procedures
CLLI
rlghncxa03w
002-002-004 002-002-005
002-002-008 002-002-009
144-212-003
1-001-3 1-001-4
PCTYPE
OTHER
795
