Notes:
1. The network portion of the IP address value of the gtwy
parameter must be the same as the network portion of the IP
addresses shown for either the A or B interfaces in the rtrv-ip-card
output.
2. The value of the dest and gtwy parameters cannot the
127.x.x.x (the loopback address), 0.0.0.0, or the IP addresses of
the A or B interfaces on the IP card, and cannot be assigned to
another IP card.
3. There can be a maximum of 64 IP routes assigned to an IP
card.
4. The EAGLE 5 ISS can contain a maximum of 1024 IP routes.
Sheet 2 of 2

Figure 97: Adding an IP Route

910-6278-001 Revision A, January 2012
From
Sheet 1
Enter the
ent-ip-rte command with these parameters:
:loc=<IP card location>
:dest = <IP address of the remote host or
network>
:submask = <subnet mask of the
destination IP address>
:gtwy = <IP address of the gateway or
router>
(See Notes 1 through 4)
Enter the
rtrv-ip-rte:loc=<card location
specified in the ent-ip-rte
command> command
Enter the
chg-db:action=backup:dest=fixed
command
IPSG M2PA and M3UA Configuration Procedures
729
