Database Administration Manual - IP7 Secure
Gateway
Large MSU Support for IP Signaling feature is enabled and turned on. UIMs are displayed when most
of these circumstances occur. These UIMs are:
UIM 1333 – Displayed when a large message is received on an M3UA association and the Large
MSU Support for IP Signaling feature is not enabled or is enabled and turned off. The large message
is discarded.
UIM 1350 – Displayed when a M2PA IP connection receives message with an SIF greater than 272
bytes and the Large MSU Support for IP Signaling feature is not enabled or is enabled and turned
off. The large message is discarded.
UIM 1352 – Displayed when a message with an SIF greater than 272 bytes is received; the Large
MSU Support for IP Signaling feature is enabled and turned on; there are routes available for the
destination point code; but the selected outbound card does not support large messages.
UIM 1353 – Displayed when a large message passes a gateway screening screenset that redirects
messages for the Database Transport Access (DTA) feature. Large messages are not redirected for
the DTA feature.
UIM 1354 – Displayed when a large message passes a gateway screening screenset that copies
messages for the STPLAN feature. Large messages are not copied for the STPLAN feature.
For more information on these UIMs, refer to the Unsolicited Alarm and Information Messages manual.
Note: Large messages are not monitored by the EAGLE 5 Integrated Monitoring Support feature and
are not sent to the IMF. A UIM is not generated.
1. Display the status of the controlled features by entering the rtrv-ctrl-feat command.
The following is an example of the possible output.
rlghncxa03w 08-04-28 21:15:37 GMT EAGLE5 38.0.0
The following features have been permanently enabled:
Feature Name
Command Class Management
LNP Short Message Service 893006601
Intermed GTT Load Sharing 893006901
XGTT Table Expansion
XMAP Table Expansion
Large System # Links
Routesets
HC-MIM SLK Capacity
The following features have been temporarily enabled:
Feature Name
Zero entries found.
The following features have expired temporary keys:
Feature Name
Zero entries found.
If the Large MSU Support for IP Signaling feature is enabled and turned on, no further action is
necessary. This procedure does not need to be performed.
If the Large MSU Support for IP Signaling feature is enabled and but not turned on, continue this
procedure with
If the Large MSU Support for IP Signaling feature is not enabled, continue this procedure with
2.
910-6278-001 Revision A, January 2012
Partnum
893005801
893006101
893007710
893005910
893006401
893012707
Partnum
Partnum
Step 7.
IPSG M2PA and M3UA Configuration Procedures
Status Quantity
on ----
on ----
on ----
on 400000
off ----
on 2000
on 6000
on 64
Status Quantity Trial Period Left
Step
