Configuring Ip Options - Tekelec IP7 Secure Gateway Administration Manual

Database Administration Manual - IP7 Secure
Gateway

Configuring IP Options

Use this procedure to change the IP options defined by these parameters: getcomm, setcomm,
snmpcont, srkq, trapcomm, ipgwabate, and uameasusedftas.
The chg-sg-opts command also contains the sctpcsum parameter. Perform the one of these
procedures to change the sctpcsum parameter value.
Changing the SCTP Checksum Algorithm Option for M3UA and SUA Associations
Changing the SCTP Checksum Algorithm Option for M2PA Associations
Changing the SCTP Checksum Algorithm Option for IPSG M2PA Associations
Changing the SCTP Checksum Algorithm Option for IPSG M3UA Associations
:getcomm – The community name used to validate SNMP Get and GetNext requests. This value applies
to each IP card SNMP agent.
:setcomm – The community name used to validate SNMP Set requests. This value applies to each IP
card SNMP agent.
:snmpcont – The system contact information for each IP card SNMP agent, used to define the sysContact
object in the SNMP MIB II System Group.
:srkq – The static routing key quantity used to specify the maximum number of static routing key
entries in the Routing Key table of each ss7ipgw and ipgwi card.
:trapcomm – The community name used when sending SNMP traps. This value applies to each IP
card SNMP agent.
:ipgwabate – enables (ipgwabate=yes) or disables (ipgwabate=no) SS7 congestion abatement
procedures for IPGWx signaling links (signaling links assigned to cards running the ss7ipgw or
ipgwi applications). The default value for this parameter is no.
:uameasusedftas - specifies whether UA measurements are pegged against the default application
server or against the application server shown by the routing context. The values for this parameter
are yes and no. The system default value for this parameter is yes.
yes - UA measurement registers are pegged against the default application server.
no - UA measurements are pegged against the application server shown by the routing context.
The maximum value of the srkq parameter is 2500.
The value specified for the srkq parameter cannot be less than the current number of provisioned
routing keys. The number of routing keys that are currently provisioned is shown in the
rtrv-appl-rtkey or rtrv-tbl-capacity command outputs.
The values of the snmpcont, getcomm, setcomm, and trapcomm parameters are a string of up to 32
characters that is not case sensitive. If the character string contains characters other than alphanumeric
characters, the character string must be enclosed in single quotes.
1. Display the current IP options in the database by entering the rtrv-sg-opts command.
The following is an example of the possible output.
rlghncxa03w 08-04-28 21:17:37 GMT EAGLE5 38.0.0
SRKQ:
SNMPCONT:
910-6278-001 Revision A, January 2012
250
john doe 555-123-4567
IPSG M2PA and M3UA Configuration Procedures
870
