Tekelec IP7 Secure Gateway Administration Manual page 871

Database Administration Manual - IP7 Secure
Gateway
GETCOMM:
SETCOMM:
TRAPCOMM:
SCTPCSUM:
IPGWABATE:
UAMEASUSEDFTAS
If the srkq parameter value will not be changed, continue the procedure with
If the srkq parameter value will be changed, verify the number of routing keys that are currently
provisioned by performing
2. Enter the rtrv-tbl-capacity command to verify the number of routing keys that are currently
provisioned.
The following is an example of the possible output.
rlghncxa03w 08-04-28 21:17:37 GMT EAGLE5 38.0.0
RTEKEY table is (
Note: The rtrv-tbl-capacity command output contains other fields that are not used by this
procedure. If you wish to see all the fields displayed by the rtrv-tbl-capacity command, see
the rtrv-tbl-capacity command description in the Commands Manual.
The number of routing keys that are currently provisioned is shown in the RTEKEY row of the
rtrv-tbl-capacity output. In this example, there are 53 routing keys provisioned in the database.
The new srkq parameter value cannot be less than 53.
3. Change the IP options in the database using the chg-sg-opts command.
For this example, enter this command.
chg-sg-opts:srkq=200:ipgwabate=yes:uameasusedftas=no
When this command has successfully completed, the following message should appear.
rlghncxa03w 08-04-28 21:18:37 GMT EAGLE5 38.0.0
CHG-SG-OPTS: MASP A - COMPLTD
4. Verify the new IP options in the database by entering the rtrv-sg-opts command.
The following is an example of the possible output.
rlghncxa03w 08-04-28 21:19:37 GMT EAGLE5 38.0.0
SRKQ:
SNMPCONT:
GETCOMM:
SETCOMM:
TRAPCOMM:
SCTPCSUM:
IPGWABATE:
UAMEASUSEDFTAS
5. Back up the new changes using the chg-db:action=backup:dest=fixed command. These
messages should appear, the active Maintenance and Administration Subsystem Processor (MASP)
appears first.
BACKUP (FIXED) : MASP A - Backup starts on active MASP.
BACKUP (FIXED) : MASP A - Backup on active MASP to fixed disk complete.
910-6278-001 Revision A, January 2012
public
private
public
crc32c
NO
YES
Step 2.
53 of
200
john doe 555-123-4567
public
private
public
crc32c
YES
NO
IPSG M2PA and M3UA Configuration Procedures
2500) 2% full
Step 3.
871
