Database Administration Manual - IP7 Secure
Gateway
If the IPGWAPC value of the linkset is yes or if the IPGWAPC and IPSG values of the linkset are
no , the linkset must be removed from the database and then an IPSG M2PA linkset must be
added. Perform the "Removing a Linkset Containing SS7 Signaling Links" procedure in the
Database Administration Manual - SS7 to remove the linkset. After the linkset has been removed,
perform the
IPSG M2PA linkset has been added, perform the
to add IPSG M2PA signaling links to the new IPSG M2PA linkset. This procedure is finished.
If the IPSG value of the linkset is yes, continue the procedure with one of these steps.
If the ADAPTER value of the linkset is M3UA, perform the
Link procedure to remove the IPSG M3UA signaling links from the linkset. After the IPSG
M3UA linksets have been removed from the linkset, continue the procedure with
If the ADAPTER value of the linkset is M2PA, continue the procedure with one of these steps.
If the RSVDSLKTPS value of the linkset will not be changed, continue the procedure
with
If the RSVDSLKTPS value of the linkset will be changed, continue the procedure with
Step
3. Change the ADAPTER value of the linkset to M2PA by entering the chg-ls command with the
adapter=m2pa parameter and the name of the linkset that is being changed. For this example,
enter this command.
chg-ls:lsn=lssg1101:adapter=m2pa
When the chg-ls command has successfully completed, this message should appear.
rlghncxa03w 08-04-20 13:34:40 GMT
Link set table is (13 of 1024) 1% full.
CHG-LS: MASP A - COMPLTD
After the ADAPTER value of the linkset has been changed, continue the procedure by performing
one of these steps.
If the RSVDSLKTPS value of the linkset will not be changed, continue the procedure with
5.
If the RSVDSLKTPS value of the linkset will be changed, continue the procedure with
4. The new RSVDSLKTPS value for the linkset cannot allow the sum of the TPS used by all the IPSG
signaling links that are assigned to each IPSG card shown in the linkset to exceed 5000 and cannot
exceed the maximum total provisioned system TPS.
To verify the TPS for the IPSG cards containing the IPSG signaling links in the linkset, enter the
rtrv-slk command with the card location of each signaling link that is assigned to the linkset.
For this example, enter these commands.
rtrv-slk:loc=1101
This is an example of the possible output.
rlghncxa03w 08-04-24 14:02:40 EST
rtrv-slk:loc=1101
Command entered at terminal #4.
910-6278-001 Revision A, January 2012
Adding an IPSG M2PA Linkset
Step 5 .
4.
IPSG M2PA and M3UA Configuration Procedures
procedure to add the IPSG M2PA linkset. After the
Adding an IPSG M2PA Signaling Link
Adding an IPSG M3UA Signaling
EAGLE5 38.0.0
38.0.0
procedure
Step 3.
Step
Step 4.
