Database Administration Manual - IP7 Secure
Gateway
:force – If the global title translation feature is on, the force=yes parameter allows the IPSG card
to be added to the database even if the current SCCP transactions-per-second threshold is unable to
support the additional SCCP transaction-per-second capacity created by adding the IP card. This
parameter is obsolete and is no longer used.
Card Slot Selection
The E5-ENET card can be inserted into any card slot, except for card slots that must remain empty to
accommodate dual-slot cards, slots 09 and 10 in each shelf, and slots 1113 through 1118.
To provision an E5-ENET card, the shelf containing the E5-ENET card must have HIPR or HIPR2
cards installed in slots 9 and 10 in that shelf. If HIPR or HIPR2 cards are not installed in the shelf that
the E5-ENET card will occupy, the E5-ENET card will be auto-inhibited when the E5-ENET card is
inserted into the shelf. Enter the rept-stat-gpl:gpl=hipr command to verify whether or not
HIPR cards are installed in the same shelf as the E5-ENET card being provisioned in this procedure.
Enter the rept-stat-gpl:gpl=hipr2 command to verify whether or not HIPR2 cards are installed
in the same shelf as the E5-ENET card being provisioned in this procedure.
1. Display the total provisioned system TPS by entering the rtrv-tps command.
This is an example of the possible output.
rlghncxa03w 10-07-30 16:20:46 GMT EAGLE 42.0.0
Total provisioned IPGW
Total provisioned IPSG
Total provisioned IPLIM
Total provisioned ATM
Total provisioned System TPS (453668 of 500000) 91%
Command Completed.
An IPSG card uses 5000 TPS. If adding the new IPSG card will not exceed the maximum total
provisioned system TPS, continue the procedure with
If adding the new IPSG card will exceed the maximum total provisioned system TPS, and the
maximum total provisioned system TPS is 500,000, perform the "Activating the HIPR2 High Rate
Mode" feature in the Database Administration Manual - System Management to enable and turn on
the HIPR2 High Rate Mode feature. When the HIPR2 High Rate Mode feature is enabled and turned
on, the maximum total provisioned system TPS is increased to 750,000. After the HIPR2 High Rate
Mode feature has been enabled and turned on, continue the procedure with
If adding the new IPSG card will exceed the maximum total provisioned system TPS, and the
maximum total provisioned system TPS is 750,000, This procedure cannot be performed. The
maximum total provisioned system TPS the EAGLE 5 ISS can have is 750,000,
2. Display the cards in the database using the rtrv-card command.
This is an example of the possible output. Cards should be distributed throughout the EAGLE 5
ISS for proper power distribution. Refer to the Installation Manual - EAGLE 5 ISS for the shelf power
distribution.
rlghncxa03w 09-03-05 08:12:53 GMT
CARD TYPE
1101 DSM
1102 TSM
1113 GSPM
1114 TDM-A
910-6278-001 Revision A, January 2012
TPS = 30000
TPS = 400000
TPS = 20000
TPS = 3668
41.0.0
APPL LSET NAME
VSCCP
GLS
EOAM
IPSG M2PA and M3UA Configuration Procedures
Step 2.
LINK SLC LSET NAME
Step 2.
LINK SLC
645
