Database Administration Manual - IP7 Secure
Gateway
Adding the IPSG M3UA linkset cannot exceed the maximum total provisioned system TPS shown in
the rtrv-tps output. An IPSG M3UA linkset uses from 100 to 5000 TPS, as provisioned by the
maxslktps parameter.
If adding the IPSG M3UA linkset will exceed the maximum total provisioned system TPS, and the
maximum total provisioned system TPS is 500,000, perform the "Activating the HIPR2 High Rate
Mode" feature in the Database Administration Manual - System Management to enable and turn on the
HIPR2 High Rate Mode feature. When the HIPR2 High Rate Mode feature is enabled and turned on,
the maximum total provisioned system TPS is increased to 750,000. If the maximum total provisioned
system TPS is 750,000, or the maximum total provisioned system TPS is 500,000 and will not be
increased, and adding the IPSG M3UA linkset will exceed the maximum total provisioned system
TPS, the IPSG M3UA linkset cannot be added unless the amount of available TPS is reduced enough
to allow the IPSG M3UA linkset to be added. The available TPS can be reduced by performing one or
more of these actions.
The IP TPS values of some IPGWx linksets have to be changed.
The MAXSLKTPS values of some IPSG linksets (and the RSVDSLKTPS values if necessary) have
to be changed.
Some ATM high-speed signaling links have to be removed.
An IPLIMx card that contains signaling links has to be removed.
Other Optional Parameters
There are other optional parameters that can be used to configure an IPSG M3UA linkset. These
parameters are not required for configuring an IPSG M3UA linkset. These parameters are discussed
in more detail in the Commands Manual or in these sections.
These procedures in this manual:
Adding a Mate IPGWx Linkset to another IPGWx Linkset
Removing a Mate IPGWx Linkset from another IPGWx Linkset
Configuring an IPGWx Linkset
These procedures in the Database Administration Manual - SS7
Adding an SS7 Linkset
Changing an SS7 Linkset
Configuring an ITU Linkset with a Secondary Adjacent Point Code (SAPC)
The "Configuring a Linkset for the GSM MAP Screening Feature" procedure in the Database
Administration Manual - Features.
Note: The mtprse, spc/spca/spci/spcn/spcn24, and ppc/ppca/ppci/ppcn/ppcn24
parameters cannot be specified for an IPSG M3UA linkset.
Canceling the RTRV-LS and RTRV-DSTN Commands
Because the rtrv-ls and rtrv-dstn commands used in this procedure can output information for
a long period of time, the rtrv-ls and rtrv-dstn commands can be canceled and the output to
the terminal stopped. There are three ways that the rtrv-ls and rtrv-dstn commands can be
canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-ls or rtrv-dstn
commands were entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-ls or rtrv-dstn
commands were entered.
