Database Administration Manual - IP7 Secure
Gateway
Canceling the RTRV-APPL-RTKEY Command
Because the rtrv-appl-rtkey command used in this procedure can output information for a long
period of time, the rtrv-appl-rtkey command can be canceled and the output to the terminal
stopped. There are three ways that the rtrv-appl-rtkey command can be canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-appl-rtkey command
was entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-appl-rtkey
command was entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rtrv-appl-rtkey
command was entered, from another terminal other that the terminal where the rtrv-appl-rtkey
command was entered. To enter the canc-cmd:trm=<xx> command, the terminal must allow
Security Administration commands to be entered from it and the user must be allowed to enter
Security Administration commands. The terminal's permissions can be verified with the
rtrv-secu-trm command. The user's permissions can be verified with the rtrv-user or
rtrv-secu-user commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the current routing key information in the database by entering the rtrv-appl-rtkey
command.
The following is an example of the possible output.
rlghncxa03w 08-04-28 21:15:37 GMT EAGLE5 38.0.0
RCONTEXT
----------
----------
----------
2500
RCONTEXT
----------
100
225
----------
----------
----------
----------
----------
----------
----------
----------
300
RCONTEXT
----------
STATIC Route Key table is (17 of 2000) 1% full
STATIC Route Key Socket Association table is (17 of 32000) 1% full
2. Display the specific routing key information for the routing key being changed by entering the
rtrv-appl-rtkey command with the display=all parameter.
If the routing key being changed contains a routing context value, specify the rcontext parameter
and value shown in the rtrv-appl-rtkey output in
910-6278-001 Revision A, January 2012
DPC SI ADPTR
123-234-123 5 M3UA
005-005-001 5 M3UA
005-005-001 5 M3UA
006-006-001 5 SUA
DPCI SI ADPTR
2-100-7 6 M3UA
3-137-6 6 SUA
4-035-7 5 SUA
6-006-6 5 M3UA
6-006-7 5 M3UA
6-006-6 5 M3UA
6-006-6 5 M3UA
6-006-8 3 M3UA
6-006-8 5 M3UA
6-024-7 5 M3UA
6-024-7 5 M3UA
7-008-7 6 SUA
DPC SI ADPTR
*********** ** M3UA
IETF M3UA and SUA Configuration Procedures
ASNAME TYPE
as12 FULL
as9 FULL
as9 FULL
as10 FULL
ASNAME TYPE
as4 FULL
as1 FULL
as7 FULL
as2 FULL
as8 FULL
as2 FULL
as2 FULL
as3 FULL
as5 FULL
as4 FULL
as4 FULL
as6 FULL
ASNAME TYPE
as11 DEFAULT
Step 1 for the routing key being changed.
