Database Administration Manual - IP7 Secure
Gateway
:ssn – The subsystem number value that is used to filter incoming MSUs.
:cics - Starting circuit identification code that is used to filter incoming MSUs.
:cice - Ending circuit identification code that is used to filter incoming MSUs.
:type - Key type. Identifies the type of routing key that will be changed. One of three values, type
=full/partial/default. If type is not explicitly specified, type = full is assumed.
:ncics - New starting circuit identification code that is used to filter incoming MSUs.
:ncice - New ending circuit identification code that is used to filter incoming MSUs.
:split - The circuit identification code value where the specified range of the routing key specified
by the cics and cice values is to be split into two entries.
See the Changing the CIC Values in an Existing Routing Key Containing an Application Server
for changing a routing key using the ncics, ncice, and split parameters.
Canceling the RTRV-APPL-RTKEY Command
Because the rtrv-appl-rtkey command used in this procedure can output information for a long
period of time, the rtrv-appl-rtkey command can be canceled and the output to the terminal
stopped. There are three ways that the rtrv-appl-rtkey command can be canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-appl-rtkey command
was entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-appl-rtkey
command was entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rtrv-appl-rtkey
command was entered, from another terminal other that the terminal where the rtrv-appl-rtkey
command was entered. To enter the canc-cmd:trm=<xx> command, the terminal must allow
Security Administration commands to be entered from it and the user must be allowed to enter
Security Administration commands. The terminal's permissions can be verified with the
rtrv-secu-trm command. The user's permissions can be verified with the rtrv-user or
rtrv-secu-user commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the current routing key information in the database by entering the rtrv-appl-rtkey
command. The following is an example of the possible output.
rlghncxa03w 08-04-28 21:15:37 GMT EAGLE5 38.0.0
RCONTEXT
----------
----------
----------
2500
RCONTEXT
----------
100
225
310
----------
1000
500
----------
----------
910-6278-001 Revision A, January 2012
DPC SI ADPTR
123-234-123 5 M3UA
005-005-001 5 M3UA
005-005-001 5 M3UA
006-006-001 5 SUA
DPCI SI ADPTR
2-100-7 6 M3UA
3-137-6 6 SUA
4-035-7 5 M3UA
6-006-6 5 SUA
6-006-7 5 M3UA
6-006-6 5 SUA
6-006-6 5 SUA
6-006-8 3 M3UA
6-006-8 5 M3UA
IETF M3UA and SUA Configuration Procedures
ASNAME TYPE
as12 FULL
as9 FULL
as9 FULL
as10 FULL
ASNAME TYPE
as4 FULL
as1 FULL
as7 FULL
as2 FULL
as8 FULL
as2 FULL
as2 FULL
as3 FULL
as5 FULL
procedure
