Database Administration Manual - IP7 Secure
Gateway
Enter the canc-cmd without the trm parameter at the terminal where the rept-stat-slk,
rtrv-ls, or rtrv-slk commands were entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rept-stat-slk, rtrv-ls,
or rtrv-slk commands were entered, from another terminal other that the terminal where the
rept-stat-slk, rtrv-ls, or rtrv-slk commands was entered. To enter the
canc-cmd:trm=<xx> command, the terminal must allow Security Administration commands to
be entered from it and the user must be allowed to enter Security Administration commands. The
terminal's permissions can be verified with the rtrv-secu-trm command. The user's permissions
can be verified with the rtrv-user or rtrv-secu-user commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the maximum number of signaling links the EAGLE 5 ISS can have and the number of
signaling links that are currently provisioned by entering the rtrv-tbl-capacity command.
This is an example of the possible output.
rlghncxa03w 09-07-19 21:16:37 GMT EAGLE5 41.1.0
SLK table is (
Note: The rtrv-tbl-capacity command output contains other fields that are not used by this
procedure. If you wish to see all the fields displayed by the rtrv-tbl-capacity command, refer
to the rtrv-tbl-capacity command description in the Commands Manual.
If the addition of the new signaling link will not exceed the maximum number of signaling links
the EAGLE 5 ISS can have, continue the procedure with
If the addition of the new signaling link will exceed the maximum number of signaling links the
EAGLE 5 ISS can have, and the maximum number of signaling links is less than 2800, perform the
Enabling the Large System # Links Controlled Feature
signaling links. After the new quantity of signaling links has been enabled, continue the procedure
Step 2.
with
If the addition of the new signaling link will exceed the maximum number of signaling links the
EAGLE 5 ISS can have (in this example, the maximum number of signaling links is 1200), and the
maximum number of signaling links is 2800, this procedure cannot be performed. The EAGLE 5
ISS cannot contain more than 2800 signaling links.
2. Display the current signaling link configuration using the rtrv-slk command.
rlghncxa03w 10-07-19 21:16:37 GMT EAGLE5 42.0.0
rtrv-slk
Command entered at terminal #4.
LOC LINK LSN
1312 A lsnds0
LOC LINK LSN
1305 A lsnds0
LOC LINK LSN
1306 A lsnituatm
LOC LINK LSN
1303 A ipsglsn
1303 A1 ipsglsn
910-6278-001 Revision A, January 2012
IPSG M2PA and M3UA Configuration Procedures
5 of 1200)
L2T
SLC TYPE SET BPS
0 LIMDS0 1 56000
LP
SLC TYPE SET BPS
1 LIMATM 1 1.544M LINE
LP
SLC TYPE SET BPS
0 LIME1ATM 21 2.048M LINE
SLC TYPE ANAME
0 IPSG ipsgm2pa1
1 IPSG ipsgm2pa2
1% full
Step 2.
procedure to enable the desired quantity of
PCR PCR
ECM N1 N2
BASIC ---- ------
ATM
TSEL VCI
5
ATM
TSEL VCI
5
SLKTPS
600
600
VPI LL
0 0
E1ATM
VPI CRC4 SI SN
0 ON 3 0
