Table 51: Valid Subnet Mask Parameter Values

Network Class
A
A+B
A+B+C
If a Class B IP address is specified for the dest parameter of the ent-ip-rte command, the subnet
address that results from the dest and submask parameter values cannot be the same as the subnet
address that results from the pvn and pvnmask , fcna and fcnamask, or fcnb and fcnbmask
parameter values of the chg-netopts command. The pvn and pvnmask , fcna and fcnamask, or
fcnb and fcnbmask parameter values can be verified by entering the rtrv-netopts command.
Choose dest and submask parameter values for the IP route whose resulting subnet address is not
be the same as the subnet address resulting from the pvn and pvnmask , fcna and fcnamask, or
fcnb and fcnbmask parameter values of the chg-netopts command.
910-6278-001 Revision A, January 2012
IP Network Address Range
1.0.0.0 to 127.0.0.0
128.1.0.0 to 191.255.0.0
192.0.0.0 to 223.255.255.0
IPSG M2PA and M3UA Configuration Procedures
Valid Subnet Mask Values
255.0.0.0 (the default value for a class A IP
address)
255.192.0.0
255.224.0.0
255.240.0.0
255.248.0.0
255.252.0.0
255.254.0.0
255.255.128.1
255.255.0.0 (the default value for a class B
IP address)
255.255.192.0
255.255.224.0
255.255.240.0
255.255.248.0
255.255.252.0
255.255.254.0
255.255.255.128
255.255.255.0 (the default value for a class
C IP address)
255.255.255.192
255.255.255.224
255.255.255.240
255.255.255.248
255.255.255.252
