Database Administration Manual - IP7 Secure
Gateway
If you do not wish to perform other actions to increase the available TPS and the available TPS will
allow the IPSG M3UA linkset to be changed, continue the procedure with
8. Display the signaling links that are assigned to IPLIMx cards by entering this command.
rtrv-slk:type=iplim
This is an example of the possible output.
rlghncxa03w 10-07-19 21:16:37 GMT EAGLE5 42.0.0
LOC LINK LSN
1301 A lsniplim
1301 A1 lsniplim
1301 B1 lsniplim
1317 A lsniplimi
SLK table is (30 of 1200) 2% full.
If IPLIMx cards containing signaling links are shown in the rtrv-slk output, perform the
an IPLIMx Card
If IPLIMx cards containing signaling links are not displayed in the rtrv-slk output, perform one
or more of these actions to increase the available TPS.
Note: If one or more of these actions are not performed to increase the available TPS and the
available TPS will not allow the IPSG M3UA linkset to be changed, the IPSG M3UA linkset cannot
be added and the remainder of this procedure cannot be performed.
The IP TPS values of some IPGWx linksets have to be changed. To perform this action, continue
the procedure with
The MAXSLKTPS values of some IPSG linksets (and the RSVDSLKTPS values if necessary) have
to be changed. To perform this action, continue the procedure with
Some ATM high-speed signaling links have to be removed. To perform this action, continue
the procedure with
If you do not wish to perform other actions to increase the available TPS and the available TPS will
allow the IPSG M3UA linkset to be changed, continue the procedure with
9. Display the IPGWx and IPSG linksets by entering this command.
rept-stat-iptps
This is an example of the possible output.
rlghncxa03w 10-07-19 21:16:37 GMT EAGLE5 42.0.0
IP TPS USAGE REPORT
THRESH
-------------------------------------------------------------------------
LSN
ipgwx1
ipgwx2
ipgwx3
ipsglsn
ipsglsn2
910-6278-001 Revision A, January 2012
SLC TYPE
0 IPLIM
1 IPLIM
2 IPLIM
0 IPLIMI
procedure to remove an IPLIMx card and its associated signaling links.
Step 9.
Step 7.
CONFIG/ CONFIG/
RSVD
100% ---- 32000
100% ---- 16000
100% ---- 32000
100% 600 24000
100% 600 4000
IPSG M2PA and M3UA Configuration Procedures
ANAME SLKTPS
M2PA
M2PA
M2PA
M2PA
TPS PEAK
MAX
TX: 3700 4000
RCV: 3650 4000
TX: 4800 5000
RCV: 4850 5000
TX: 427
RCV: 312
TX: 4800 5000
RCV: 4800 5000
TX: 427
Step 12.
Step 9.
Step 12.
PEAKTIMESTAMP
10-07-19 09:49:19
10-07-19 09:49:19
10-07-19 09:49:09
10-07-19 09:49:09
550 10-07-19 09:49:19
450 10-07-19 09:49:19
10-07-19 09:49:19
10-07-19 09:49:19
550 10-07-19 09:49:19
Removing
