Management to enable and turn on the HIPR2 High Rate Mode feature. When the HIPR2 High Rate
Mode feature is enabled and turned on, the maximum total provisioned system TPS is increased
to 750,000. After the HIPR2 High Rate Mode feature has been enabled and turned on, continue the
procedure with
If the maximum total provisioned system TPS is 750,000, or the maximum total provisioned system
TPS is 500,000 and will not be increased, and adding the IPSG M3UA linkset will exceed the
maximum total provisioned system TPS, the IPSG M3UA linkset cannot be added unless the amount
of available TPS is reduced enough to allow the IPSG M3UA linkset to be changed. The available
TPS can be increased by performing one or more of these actions.
The IP TPS values of some IPGWx linksets have to be changed. To perform this action, continue
the procedure with
The MAXSLKTPS values of some IPSG linksets (and the RSVDSLKTPS values if necessary) have
to be changed. To perform this action, continue the procedure with
Some ATM high-speed signaling links have to be removed. To perform this action, continue
the procedure with
An IPLIMx card that contains signaling links has to be removed. To perform this action, continue
the procedure with
7. Display the ATM high-speed signaling links by entering this command.
rtrv-slk:type=saal
This is an example of the possible output.
rlghncxa03w 10-07-19 21:16:37 GMT EAGLE5 42.0.0
LOC LINK LSN
1303 A lsnds0
LOC LINK LSN
1306 A lsnituatm
SLK table is (30 of 1200) 2% full.
If ATM high-speed signaling links are shown in the rtrv-slk output, perform the "Removing an
SS7 Signaling Link" procedure in the Database Administration Manual - SS7 to remove some of the
ATM high-speed signaling links.
If ATM high-speed signaling links are not displayed in the rtrv-slk output, perform one or more
of these actions to increase the available TPS.
Note: If one or more of these actions are not performed to increase the available TPS and the
available TPS will not allow the IPSG M3UA linkset to be changed, the IPSG M3UA linkset cannot
be added and the remainder of this procedure cannot be performed.
The IP TPS values of some IPGWx linksets have to be changed. To perform this action, continue
the procedure with
The MAXSLKTPS values of some IPSG linksets (and the RSVDSLKTPS values if necessary) have
to be changed. To perform this action, continue the procedure with
An IPLIMx card that contains signaling links has to be removed. To perform this action, continue
the procedure with
910-6278-001 Revision A, January 2012
Step 12.
Step 9.
Step 7.
Step 8.
SLC TYPE
1 LIMATM
SLC TYPE
0 LIME1ATM 21
Step 9.
Step 8.
IPSG M2PA and M3UA Configuration Procedures
LP ATM
SET BPS TSEL
1 1.544M LINE
LP ATM
SET BPS TSEL
2.048M LINE
Step 9.
VCI VPI LL
5 0 0
E1ATM
VCI VPI CRC4 SI SN
5 0 ON 3
Step 9.
