Tekelec IP7 Secure Gateway Administration Manual page 373

Database Administration Manual - IP7 Secure
Gateway
Because the rtrv-assoc command used in this procedure can output information for a long period
of time, the rtrv-assoc command can be canceled and the output to the terminal stopped. There
are three ways that the rtrv-assoc command can be canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-assoc command was
entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-assoc command
was entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rtrv-assoc command
was entered, from another terminal other that the terminal where the rtrv-assoc command was
entered. To enter the canc-cmd:trm=<xx> command, the terminal must allow Security
Administration commands to be entered from it and the user must be allowed to enter Security
Administration commands. The terminal's permissions can be verified with the rtrv-secu-trm
command. The user's permissions can be verified with the rtrv-user or rtrv-secu-user
commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the associations in the database using the rtrv-assoc command. This is an example of
possible output.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
ANAME
swbel32
a2
a3
assoc3
Perform one of these actions.
If SUA associations are assigned to the desired IP link (shown by the entries in the CARD LOC
and IPLNK PORT columns for an association whose ADAPTER value is SUA in the rtrv-assoc
output), continue the procedure with
If M3UA associations are assigned to the desired IP link (shown by the entries in the CARD LOC
and IPLNK PORT columns for an association whose ADAPTER value is M3UA in the rtrv-assoc
output), continue the procedure with
If the desired IP link is not shown in the rtrv-assoc output, continue the procedure with
3.
2. Display the signaling links assigned to the card that the new M3UA association will be assigned
to by entering the rtrv-slk command with the card location displayed in
enter this command.
rtrv-slk:loc=1201
The following is an example of the possible output.
rlghncxa03w 08-04-06 10:07:25 GMT EAGLE5 38.0.0
LOC LINK LSN
1201 A lsn1
If the value in the TYPE column is either SS7IPGW or IPGWI, continue the procedure with
If the value in the TYPE column is IPSG, the links and host assigned to this card cannot be used in
this procedure. If you wish to use this card to configure an M3UA association, perform the
an IPSG M3UA Association
910-6278-001 Revision A, January 2012
CARD IPLNK
LOC PORT LINK ADAPTER LPORT RPORT OPEN ALW
1201 A A M3UA
1305 A A SUA
1307 A A SUA
1203 A A1 M2PA
Step
Step
SLC TYPE
0 SS7IPGW
procedure.
IETF M3UA and SUA Configuration Procedures
1030 2345 YES
1030 2345 YES
1030 2346 YES
2048 1030 NO
5.
2.
YES
YES
YES
NO
Step 1. For this example,
Step
Adding
Step
5.
373
