Database Administration Manual - IP7 Secure
Gateway
1205 114-000-000
ALARM STATUS
BPDCM GPL
IMT BUS A
IMT BUS B
SIGNALING LINK STATUS
SLK
A
Command Completed.
If the link value will not be changed, continue the procedure with
If the link value will be changed, continue the procedure with
11. Display the signaling link that will be assigned to the association by entering the rtrv-slk
command and specifying the card location and signaling link.
For this example, enter this command.
rtrv-slk:loc=1203
This is an example of the possible output.
rlghncxa03w 08-04-19 21:17:04 GMT EAGLE5 38.0.0
LOC LINK LSN
1203 A e5e6a
If the required IPGWx signaling is shown in this step, continue the procedure with
If the required IPGWx signaling is not shown in this step, perform the
Link to add the required IPGWx signaling link. After the signaling link has been added, continue
the procedure with
12. Change the association using the chg-assoc command.
For this example, enter this command.
chg-assoc:aname=assoc2:lhost=m3ua1:alhost=m3ua2:rhost= gw200.nc-tekelec.com
These are the rules that apply to the chg-assoc command.
If any optional parameters are not specified with the chg-assoc command, those values are
not changed.
Single-slot EDCMs or E5-ENET cards can use the B Ethernet interface.
The number of association – application server assignments on an IPGWx card cannot exceed
50.
The EAGLE 5 ISS can contain a maximum of 4000 connections.
The value of the lhost and rhost parameters is a text string of up to 60 characters, with the
first character being a letter. The command input is limited to 150 characters, including the
hostnames.
Specifying the lhost parameter only creates a uni-homed endpoint. The network portion of
the endpoint's IP address must be the same as the network portion of the IP address assigned
to either the A or B network interface of the IP card.
Specifying the lhost and alhost parameters creates a multi-homed endpoint. The network
portion of the IP address associated with the lhost parameter must be the same as the network
portion of the IP address assigned to one of the network interfaces (A or B) of the IP card, and
the network portion of the IP address associated with the alhost parameter must be the same
as the network portion of the IP address assigned to the other network interface on the IP card.
910-6278-001 Revision A, January 2012
DCM SS7IPGW
= No Alarms.
= 002-102-000
= Conn
= Conn
PST
IS-NR
SLC TYPE
1 SS7IPGW
Step 12.
IETF M3UA and SUA Configuration Procedures
IS-NR
LS CLLI
nc001 -----------
Active -----
Step 12.
Step 11.
Step
Adding an IPGWx Signaling
12.
