Removing a Mate IPGWx Linkset from another IPGWx Linkset

This procedure is used to remove a mate IPGWx linkset from an existing IPGWx linkset chg-ls
command with these parameters.
:lsn – The name of the IPGWx linkset that contains the mate IPGWx Linkset that is being removed,
shown in the rept-stat-iptps or rtrv-ls command outputs.
:matelsn – The name of the mate IPGWx linkset that is being removed.
:action=delete – removes the mate IPGWx linkset from the IPGWx linkset specified by the lsn
parameter.
An IPGWx linkset is a linkset that contains signaling links assigned to IPGWx cards. IPGWx cards are
cards running either the SS7IPGW or IPGWI applications.
The mate linkset name is displayed in the rtrv-ls:lsn=<linkset name> command output.
Before a mate IPGWx linkset can be removed from an IPGWx linkset, the card containing the IPGWx
signaling link assigned to the mate linkset, and the signaling link assigned to that card must be placed
out of service.
Other Optional Parameters
There are other optional parameters that can be used to configure a linkset. These parameters are not
required for configuring an IPGWx linkset. These parameters are discussed in more detail in the
Commands Manual or in these sections.
These procedures in this manual:
Configuring an IPGWx Linkset
Adding a Mate IPGWx Linkset to another IPGWx Linkset
Adding an IPSG M3UA Linkset
Adding an IPSG M2PA Linkset
Changing an IPSG M3UA Linkset
Changing an IPSG M2PA Linkset
These procedures in the Database Administration Manual - SS7
Adding an SS7 Linkset
Changing an SS7 Linkset
Configuring an ITU Linkset with a Secondary Adjacent Point Code (SAPC)
The "Configuring a Linkset for the GSM MAP Screening Feature" procedure in the Database
Administration Manual - Features.
1. Display the system-wide IP TPS usage report, and the IPGWx linksets, by entering the
rept-stat-iptps command. This is an example of the possible output.
rlghncxa03w 10-07-19 21:16:37 GMT EAGLE5 42.0.0
IP TPS USAGE REPORT
THRESH
--------------------------------------------------------------------------
LSN
910-6278-001 Revision A, January 2012
CONFIG/ CONFIG/
RSVD MAX
IETF M3UA and SUA Configuration Procedures
TPS PEAK PEAKTIMESTAMP
469
