Database Administration Manual - IP7 Secure
Gateway
Attributes of an IPSG Association
Commands Manual.
Canceling the RTRV-ASSOC Command
Because the rtrv-assoc command used in this procedure can output information for a long period
of time, the rtrv-assoc command can be canceled and the output to the terminal stopped. There
are three ways that the rtrv-assoc command can be canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-assoc command was
entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-assoc command
was entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rtrv-assoc command
was entered, from another terminal other that the terminal where the rtrv-assoc command was
entered. To enter the canc-cmd:trm=<xx> command, the terminal must allow Security
Administration commands to be entered from it and the user must be allowed to enter Security
Administration commands. The terminal's permissions can be verified with the rtrv-secu-trm
command. The user's permissions can be verified with the rtrv-user or rtrv-secu-user
commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the associations in the database using the rtrv-assoc command.
This is an example of possible output.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
ANAME
swbel32
a2
a3
assoc1
2. Enter the rtrv-card command with the location of the card that is hosting the M2PA association
that will be changed in this procedure. For this example, enter this command.
rtrv-card:loc=1201
This is an example of possible output.
rlghncxa03w 08-03-06 15:17:20 EST EAGLE5 38.0.0
CARD TYPE
1201 DCM
If the application assigned to the card is IPSG, shown in the APPL column, continue the procedure
with Step 3.
If the application assigned to the card is IPLIM or IPLIMI, perform the
Retransmission Control for a M2PA Association
If the application assigned to the card is SS7IPGW or IPGWI, perform the
Retransmission Control for a M3UA or SUA Association
3. Display the association that will be changed by entering the rtrv-assoc command with the name
of the association. For this example, enter this command.
910-6278-001 Revision A, January 2012
procedure, or in the and chg-assoc command description in the
CARD IPLNK
LOC PORT LINK ADAPTER LPORT RPORT OPEN ALW
1201 A A M3UA
1305 A A SUA
1307 A A SUA
1201 A A M2PA
APPL LSET NAME
IPLIM lsn1
IPSG M2PA and M3UA Configuration Procedures
1030 2345 YES
1030 2345 YES
1030 2346 YES
2000 1030 YES
LINK SLC LSET NAME
A 0
procedure.
procedure.
YES
YES
YES
YES
LINK SLC
Configuring SCTP
Configuring SCTP
