4. Display the attributes of the APC of the linkset being removed by entering the rtrv-dstn command
with the APC of the linkset. For this example, enter this command.
rtrv-dstn:dpca=150-001-002
This is an example of the possible output.
rlghncxa03w 10-12-15 09:22:39 GMT EAGLE5 43.0.0
DPCA
150-001-002
PPCA
150-001-001
Destination table is (14 of 2000) 1% full
Alias table is (0 of 12000) 0% full
PPC table is (2 of 10) 20% full
A proxy linkset whose APC is assigned to more than one proxy linkset cannot be removed if the
linkset contains the proxy point code (shown in the PPCA/PPCI/PPCN/PPCN24 field in
that is also assigned to the APC of the linkset (shown in
the proxy point code that is assigned to the APC of the linkset must be removed before the linkset
containing proxy point code that is assigned to the APC of the linkset can be removed.
5. Display the routes in the database by using the rtrv-rte command, specifying the name of the
linkset you wish to remove. For this example, enter this command.
rtrv-rte:lsn=ls1
This is an example of the possible output.
rlghncxa03w 07-05-10 11:43:04 GMT EAGLE5 37.0.0
LSN
RC
ls1
If any routes reference the linkset to be removed, remove these routes by performing the "Removing
a Route" procedure in the Database Administration Manual - SS7.
6. Remove all links in the linkset by performing one of these procedures.
If the ADAPTER value of the linkset is M2PA, shown in the rtrv-ls output in
Removing an IPSG M2PA Signaling Link
If the ADAPTER value of the linkset is M3UA, shown in the rtrv-ls output in
Removing an IPSG M3UA Signaling Link
7. Display any entires in the route exception table whose linkset name is the name of the linkset being
removed in this procedure. Enter the rtrv-rtx command with the lsn parameter. For this
example, enter this command.
rtrv-rtx:lsn=ls1
This is an example of the possible output.
rlghncxa03w 07-05-10 11:43:04 GMT EAGLE5 37.0.0
DPCA
240-012-006
910-6278-001 Revision A, January 2012
CLLI BEI ELEI
----------- no
NCAI PRX RCAUSE NPRST SPLITIAM HMSMSC HMSCP SCCPMSGCNV
---- no 50
DPC
240-012-004 10
procedure.
RTX-CRITERIA
OPCA
008-008-008
IPSG M2PA and M3UA Configuration Procedures
ALIASI
--- --------------
on 20
Step 4
procedure.
LSN
ls1
ALIASN/N24
--------------
no no none
). The linksets that do not contain
Step 2, perform the
Step 2, perform the
RC APC
40 240-012-004
DMN
SS7
Step 3)
