Adding an IPSG M2PA Signaling Link

This procedure is used to add an IPSG M2PA signaling link to the database using the ent-slk
command. An IPSG M2PA signaling link is a signaling link that is assigned to an IPSG card and that
contains an IPSG linkset and IPSG association whose ADAPTER value is M2PA. The ent-slk command
uses these parameters to add an IPSG M2PA signaling link.
:loc – The card location of the IPSG card that the IPSG M2PA signaling link will be assigned to. The
cards specified by this parameter are E5-ENETcards running the IPSG application.
:link – The signaling link on the card specified in the loc parameter.
:lsn – The name of the linkset that will contain the signaling link.
:slc – The signaling link code. The SLC must be unique within the linkset. It must be the same at
both the EAGLE 5 ISS location and the distant node.
:aname – The name of the IPSG M2PA association that will be assigned to the IPSG M2PA signaling
link.
The ent-slk command contains other optional parameters that are not used to configure an IPGWx
signaling link. These parameters are discussed in more detail in the Commands Manual or in these
sections.
These procedures in this manual:
Adding an IPLIMx Signaling Link
Adding an IPGWx Signaling Link
These procedures in the Database Administration Manual - SS7
Adding an SS7 Signaling Link
Adding an E1 Signaling Link
Adding a T1 Signaling Link
Adding an ATM High-Speed Signaling Link
These items must be configured in the database before an IPSG M2PA signaling link can be added:
Shelf – perform the "Adding a Shelf" procedure in the Database Administration Manual - System
Management.
IPSG Card – perform the
Destination Point Code – perform the "Adding a Destination Point Code" procedure in the Database
Administration Manual - SS7 .
IPSG M2PA Linkset – perform the
IPSG M2PA Association - perform the
Verify that the link has been physically installed (all cable connections have been made).
To configure the EAGLE 5 ISS to perform circular routing detection test on the signaling links,
"Configuring Circular Route Detection" procedure in the Database Administration Manual - SS7 .
Note: Circular route detection is not supported in ITU networks.
910-6278-001 Revision A, January 2012
IPSG M2PA and M3UA Configuration Procedures
Adding an IPSG Card procedure.
Adding an IPSG M2PA Linkset
Adding an IPSG M2PA Association
procedure.
procedure.
