Database Administration Manual - IP7 Secure
Gateway
2101 A 192.1.1.20
2101 B --------------- --------------- HALF
2103 A 192.1.1.22
2103 B --------------- --------------- HALF
2105 A 192.1.1.24
2105 B --------------- --------------- HALF
2207 A 192.1.1.32
2207 B --------------- --------------- HALF
2213 A 192.1.1.50
2213 B --------------- --------------- HALF
2301 A 192.1.1.52
2301 B --------------- --------------- HALF
IP-LNK table is (20 of 2048) 1 % full.
If a local host is being configured in this procedure, the IP address assigned to the local host must
be shown in the rtrv-ip-lnk output. If the IP address is not shown in the rtrv-ip-lnk output,
add the IP address by performing the
If a remote host is being configured in this procedure, the IP address assigned to the remote host
cannot be shown in the rtrv-ip-lnk output.
3. Add IP host information to the database by entering the ent-ip-host command.
If a local host is being configured, enter the ent-ip-host command with the IP address from
Step 2, and the type=local parameter or without the type parameter. If the type parameter is
not specified with the ent-ip-host command, the type parameter value defaults to local.
If a remote host is being configured, enter the ent-ip-host command with the IP address that
is not shown in
For example, enter this command.
ent-ip-host:host= kc-hlr1 :ipaddr=192.1.1.30
When this command has successfully completed, the following message should appear.
rlghncxa03w 06-10-28 21:18:37 GMT EAGLE5 36.0.0
ENT-IP-HOST: MASP A - COMPLTD
4. Verify the new IP host information in the database by entering the rtrv-ip-host command with
the host parameter value specified in
For this example, enter this command.
rtrv-ip-host:host= kc-hlr1
The following is an example of the possible output.
rlghncxa03w 08-12-28 21:19:37 GMT EAGLE5 40.0.0
LOCAL IPADDR
192.1.1.30
IP Host table is (11 of 2048) 1% full
5. Back up the new changes using the chg-db:action=backup:dest=fixed command.
These messages should appear, the active Maintenance and Administration Subsystem Processor
(MASP) appears first.
BACKUP (FIXED) : MASP A - Backup starts on active MASP.
BACKUP (FIXED) : MASP A - Backup on active MASP to fixed disk complete.
910-6278-001 Revision A, January 2012
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
Configuring an IP Link
Step 2, and the type=remote parameter.
LOCAL HOST
KC-HLR1
IPSG M2PA and M3UA Configuration Procedures
FULL
FULL
FULL
FULL
FULL
FULL
procedure.
Step 3.
100 DIX NO
10 DIX NO
100 DIX NO
10 DIX NO
100 DIX NO
10 DIX NO
100 DIX NO
10 DIX NO
100 DIX NO
10 DIX NO
100 DIX NO
10 DIX NO
NO
NO
NO
NO
NO
NO
NO
NO
NO
NO
NO
NO
711
