Database Administration Manual - IP7 Secure
Gateway

Table 37: Examples of IPGWx Card Provisioning Limits

Number of Associations hosted
by the IPGWx card
1
50
25
25
0
38
19
* The EAGLE 5 ISS can contain a maximum of 250 application servers.
The EAGLE 5 ISS can contain a maximum of 4000 connections.
The B Ethernet interface of the IP card can be used on the single-slot EDCMs or E5-ENET cards.
If the card's application is either SS7IPGW or IPGWI, the signaling link being assigned to the association
must be in service. This state is shown in the rept-stat-slk output with the entries IS-NR in the
PST field and Avail in the SST field.
Uni-homed endpoints are associations configured with the lhost parameter only. The lhost parameter
value represents an IP address that corresponds to either the A or B network interface of the IP card.
Multi-homed endpoints are associations configured with both the lhost and alhost parameters.
The lhost parameter value represents an IP address corresponding to one of the network interfaces
(A or B) of the IP card while the alhost parameter value represents an IP address corresponding to
the other network interface of the same IP card.
The alhost=none parameter removes the alternate local host from the specified association, which
also removes the multi-homed endpoint capability.
Canceling the RTRV-ASSOC and RTRV-AS Commands
Because the rtrv-assoc and rtrv-as commands used in this procedure can output information
for a long period of time, the rtrv-assoc and rtrv-as commands can be canceled and the output
to the terminal stopped. There are three ways that the rtrv-assoc and rtrv-as commands can be
canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-assoc or rtrv-as
commands were entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-assoc or rtrv-as
commands were entered.
910-6278-001 Revision A, January 2012
IETF M3UA and SUA Configuration Procedures
Number of Application Servers
each Association is Assigned
to *
50
1
1
2
0
1
2
Total Association - Application
Server Assignments maintained
by the IPGWx card
50
50
50
50
50
38
38
