Database Administration Manual - IP7 Secure
Gateway
The IP address and subnet mask values cannot be changed to an address representing a different
network if:
If the network interface specified by the loc and port parameters has a default router, dnsa, or
dsnb parameter values assigned to it, as shown in the rtrv-ip-card output.
Any IP routes, shown in the rtrv-ip-rte output, reference the IP address for the network interface
specified by the loc and port parameters.
The IP link cannot be changed if open associations reference the IP link being changed.
The network portion of the IP addresses assigned to the IP links on an IP card must be unique. For
example, if IP links are assigned to IP card 1103, the network portion of the IP address for Ethernet
interface A (port=a) must be different from the IP address for Ethernet interface B (port=b).
The submask parameter value is based upon the ipadddr setting. See
Parameter Values

Table 49: Valid Subnet Mask Parameter Values

Network Class
A
A+B
A+B+C
910-6278-001 Revision A, January 2012
for the valid input values for the submask and ipaddr parameter combinations.
IP Network Address Range
1.0.0.0 to 127.0.0.0
128.0.0.0 to 191.255.0.0
192.0.0.0 to 223.255.255.0
IPSG M2PA and M3UA Configuration Procedures
Valid Subnet Mask Values
255.0.0.0 (the default value for a class A IP
address)
255.192.0.0
255.224.0.0
255.240.0.0
255.248.0.0
255.252.0.0
255.254.0.0
255.255.128.1
255.255.0.0 (the default value for a class B IP
address)
255.255.192.0
255.255.224.0
255.255.240.0
255.255.248.0
255.255.252.0
255.255.254.0
255.255.255.128
255.255.255.0 (the default value for a class C
IP address)
255.255.255.192
Table 49: Valid Subnet Mask
