Database Administration Manual - IP7 Secure
Gateway
m2pa
TPSALM
rsvdslktps 100%
LOC
1303 B3
Link set table is (8 of 1024) 1% full.
Perform one or both of these actions as necessary.
Perform the
shown in the rtrv-ls output whose IPGWAPC value is yes.
Perform the
and ADAPTER value is M2PA) or the
whose IPSG value is yes and ADAPTER value is M3UA) to change the MAXSLKTPS value (and
RSVDSLKTPS value if necessary) for any linksets shown in the rtrv-ls output.
Perform one or both of these actions to increase the available TPS if needed.
An IPLIMx card that contains signaling links has to be removed. To perform this action, continue
the procedure with
Some ATM high-speed signaling links have to be removed. To perform this action, continue
the procedure with
If you do not wish to perform other actions to increase the available TPS and the available TPS will
allow the IPSG M3UA linkset to be added, continue the procedure with
12. Add the new linkset to the database using the ent-ls command. The new linkset must meet these
conditions.
The name of this linkset cannot be used by another linkset – the linkset configuration is shown in
the output of
The APC of the new linkset must be in the destination point code table, but cannot be either the
EAGLE 5 ISS's point code or the EAGLE 5 ISS's capability point code – shown in the outputs of
Step 2, Step 3, and
:apc/apca – ANSI point code, ANSI private point code
:apci – ITU-I point code, ITU-I spare point code, ITU-I private point code, ITU-I private spare
point code.
:apcn – 14-bit ITU-N point code, 14-bit ITU-N spare point code, 14-bit ITU-N private point code,
14-bit ITU-N private spare point code.
:apcn24 – 24-bit ITU-N point code, 24-bit ITU-N private point code.
These parameters and values must also be specified for the IPSG M3UA linkset:
ipsg=yes
adapter=m3ua
lst=a
maxslktps=<100 - 5000>
rsvdslktps=<0 - 5000>
Note: The maxslktps parameter value must be greater than or equal to the rsvdslktps
parameter value. The slktps parameter can be used in place of the rsvdslktps parameter.
910-6278-001 Revision A, January 2012
600
LSUSEALM
LINK SLC TYPE
0 IPSG
Configuring an IPGWx Linkset
Changing an IPSG M2PA Linkset
Step 9.
Step 8.
Step 1.
Step 4. The adjacent point code can be one of the following types of point codes:
IPSG M2PA and M3UA Configuration Procedures
4000
SLKUSEALM
100%
ANAME
ipsgm2pa6
procedure to change the IPTPS value for any linksets
procedure (for linkset whose IPSG value is yes
Changing an IPSG M3UA Linkset procedure (for linkset
Step 12.
