Database Administration Manual - IP7 Secure
Gateway
Network Class
If a Class B IP address is specified for the ipaddr parameter of the chg-ip-lnk command, the subnet
address that results from the ipaddr and submask parameter values cannot be the same as the subnet
address that results from the pvn and pvnmask , fcna and fcnamask, or fcnb and fcnbmask
parameter values of the chg-netopts command. The pvn and pvnmask , fcna and fcnamask, or
fcnb and fcnbmask parameter values can be verified by entering the rtrv-netopts command.
Choose ipaddr and submask parameter values for the IP link whose resulting subnet address is not
be the same as the subnet address resulting from the pvn and pvnmask , fcna and fcnamask, or
fcnb and fcnbmask parameter values of the chg-netopts command.
Canceling the RTRV-ASSOC Command
Because the rtrv-assoc command used in this procedure can output information for a long period
of time, the rtrv-assoc command can be canceled and the output to the terminal stopped. There
are three ways that the rtrv-assoc command can be canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-assoc command was
were entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-assoc command
was entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rtrv-assoc command
was entered, from another terminal other that the terminal where the rtrv-assoc command was
entered. To enter the canc-cmd:trm=<xx> command, the terminal must allow Security
Administration commands to be entered from it and the user must be allowed to enter Security
Administration commands. The terminal's permissions can be verified with the rtrv-secu-trm
command. The user's permissions can be verified with the rtrv-user or rtrv-secu-user
commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the current link parameters associated with the IP card in the database by entering the
rtrv-ip-lnk command.
The following is an example of the possible output.
rlghncxa03w 08-12-28 21:14:37 GMT EAGLE5 40.0.0
LOC PORT IPADDR
1201 A 192.1.1.10
1201 B --------------- --------------- HALF
1203 A 192.1.1.12
1203 B --------------- --------------- HALF
1205 A 192.1.1.14
1205 B --------------- --------------- HALF
2101 A 192.1.1.20
2101 B --------------- --------------- HALF
2103 A 192.1.1.22
2103 B --------------- --------------- HALF
2105 A 192.1.1.24
910-6278-001 Revision A, January 2012
IP Network Address Range
SUBMASK
255.255.255.128 HALF
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
255.255.255.0
IPSG M2PA and M3UA Configuration Procedures
Valid Subnet Mask Values
255.255.255.224
255.255.255.240
255.255.255.248
255.255.255.252
DUPLEX SPEED MACTYPE AUTO MCAST
10
10
---- ---
10
FULL 100
10
FULL 100
10
FULL 100
10
FULL 100
802.3 NO NO
DIX NO NO
DIX YES NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
DIX NO NO
