Database Administration Manual - IP7 Secure
Gateway
If ATM high-speed signaling links are not displayed in the rtrv-slk output, perform one or more
of these actions to increase the available TPS.
Note: If one or more of these actions are not performed to increase the available TPS and the
available TPS will not allow the IPSG M3UA signaling link to be added, the IPSG M3UA signaling
link cannot be added and the remainder of this procedure cannot be performed.
An IPLIMx card that contains signaling links has to be removed. To perform this action, continue
the procedure with
The IP TPS values of some IPGWx linksets have to be changed or the MAXSLKTPS values of
some IPSG linksets (and the RSVDSLKTPS values if necessary) have to be changed.
If linksets are displayed in the rept-stat-iptps output in
with Step 10.
If linksets are not displayed in the rept-stat-iptps output in
contains signaling links has to be removed. To perform this action, continue the procedure with
Step 9.
If you do not wish to perform other actions to increase the available TPS and the available TPS will
allow the IPSG M3UA signaling link to be added, continue the procedure with
9. Display the signaling links that are assigned to IPLIMx cards by entering this command.
rtrv-slk:type=iplim
This is an example of the possible output.
rlghncxa03w 10-07-19 21:16:37 GMT EAGLE5 42.0.0
LOC LINK LSN
1301 A lsniplim
1301 A1 lsniplim
1301 B1 lsniplim
1317 A lsniplimi
SLK table is (30 of 1200) 2% full.
If IPLIMx cards containing signaling links are shown in the rtrv-slk output, perform the
an IPLIMx Card
If IPLIMx cards containing signaling links are not displayed in the rtrv-slk output, perform one
or more of these actions to increase the available TPS.
Note: If one or more of these actions are not performed to increase the available TPS and the
available TPS will not allow the IPSG M3UA signaling link to be added, the IPSG M3UA signaling
link cannot be added and the remainder of this procedure cannot be performed.
Some ATM high-speed signaling links have to be removed. To perform this action, continue
the procedure with
The IP TPS values of some IPGWx linksets have to be changed or the MAXSLKTPS values of
some IPSG linksets (and the RSVDSLKTPS values if necessary) have to be changed.
If linksets are displayed in the rept-stat-iptps output in
with Step 10.
If linksets are not displayed in the rept-stat-iptps output in
signaling links have to be removed. To perform this action, continue the procedure with
8.
910-6278-001 Revision A, January 2012
Step 9.
SLC TYPE
0 IPLIM
1 IPLIM
2 IPLIM
0 IPLIMI
procedure to remove an IPLIMx card and its associated signaling links.
Step 8.
IPSG M2PA and M3UA Configuration Procedures
ANAME SLKTPS
M2PA
M2PA
M2PA
M2PA
Step 5, continue the procedure
Step 5, an IPLIMx card that
Step 11.
Step 5, continue the procedure
Step 5, some ATM high-speed
Removing
Step
