Database Administration Manual - IP7 Secure
Gateway
From
Sheets 2, 3,
4, or 5
Enter the ent-slk command. Use the IPSG M2PA
Signaling Link Parameter Combinations table in the
Adding an IPSG M2PA Signaling Link" procedure in
the Database Administration Manual - IP7 Secure
Gateway as a guide to determine which parameters to
specify with the ent-slk command.
If adding the new signaling link will result in more than
700 signaling links in the database and the
OAMHCMEAS value in the rtrv-measopts output is on,
the scheduled UI measurement reports will be
Enter the rtrv-slk command with these
parameters for each signaling link added
with the ent-slk command.
:loc=<card location specified in the
:link = <the link parameter value
specified in the ent-slk command>
Enter the act-slk command with these
parameters for each signaling link added
with the ent-slk command.
:loc=<card location specified in the
:link = <the link parameter value
specified in the ent-slk command>
Enter the rept-stat-slk command with
these parameters for each signaling link
added with the ent-slk command.
:loc=<card location specified in the
:link = <the link parameter value
specified in the ent-slk command>
Enter the chg-assoc command
with these parameters.
:aname=<the name of the
association assigned to the
Sheet 6 of 6

Figure 100: Adding an IPSG M2PA Signaling Link

910-6278-001 Revision A, January 2012
Enter the rtrv-assoc command
with this parameter.
:loc=<the location of the IPSG
card that the signaling link will
be assigned to>
disabled.
ent-slk command>
ent-slk command>
ent-slk command>
signaling link>
:open=yes
:alw=yes
IPSG M2PA and M3UA Configuration Procedures
Are any entries
No
shown in the rtrv-assoc
output? See
the Note.
Yes
Perform the Adding an IPSG
M2PA Association" procedure to
add the IPSG M2PA association .
This association must be
assigned to the IPSG card that
the IPSG M2PA signaling link will
Is the signaling
Yes
link the first link on the
card?
No
rst-card:loc=<card location
specified in the ent-slk
command> command for
each card that signaling links
were added to for the first
Note: The association that can be assigned to an
IPSG M2PA signaling link must be an association
whose ADAPTER value is M2PA and is not assigned
to a signaling link (dashes are shown in the LINK
column of the rtrv-assoc output).
Enter the
chg-db:action=backup:dest=fixed
command.
be assigned to.
Enter the
time.
770
