Figure 28: Adding An M2Pa Association - Tekelec IP7 Secure Gateway Administration Manual

Database Administration Manual - IP7 Secure
Gateway
From
Sheet 2
Enter the act-slk command
with these parameters.
:loc = <card location of the IP
:link = <signaling link assigned
Notes:
1. The B Ethernet interface can be used with single-slot EDCMs or E5-ENET cards.
2. The EAGLE 5 ISS can contain a maximum of 4000 connections (association – application server assignments plus sockets).
3. The adapter parameter value for the association must be m2pa. The value of the ipliml2 parameter of the signaling link being
assigned to this association must be m2pa. The default value for the adapter parameter is m2pa.
4. IPLIMx cards can have only one connection for each signaling link assigned to the card. If the card is a single-slot EDCM, the card
may contain a maximum of eight connections. If the card is an E5-ENET card, the card may contain a maximum of 16 connections.
5. The value of the lhost, rhost, or alhost parameters is a text string of up to 60 characters, with the first character being a letter. The
command line on the terminal can contain up to 150 characters. If the host names are too long to fit on the ent-assoc command line,
perform the chg-assoc command with the parameters and values necessary to complete the entry of the M2PA association .
6. If the new association is to be activated in this procedure with the chg-assoc command, the association must contain values for the
lhost, rhost, lport, and rport parameters.
7. If the lhost and alhost are specified, the lhost parameter value represents the IP address corresponding to one of the network
interfaces (A or B) on the IP card while the alhost parameter value represents the IP address corresponding to the other network
interface of the same IP card.
8. The m2patset parameter can be specified only with the adapter=m2pa parameter.
9. The m2patset parameter value defaults to M2PA timer set 1 (m2patset=1) if the m2patset parameter is not specified.
10. The port parameter can be used in place of the link parameter to specify the signaling link assigned to the association.
11. When the adapter=m2pa parameter is specified, the RFC M2PA version is assigned to the M 2PA association by default . If you wish
to assign the Draft 6 M2PA version to this association , perform the Changing the Attributes of an M2PA Association" procedure in this
chapter after this procedure is completed to change the M2PA version of this association .
Sheet 3 of 3

Figure 28: Adding an M2PA Association

910-6278-001 Revision A, January 2012
Enter the
ent-assoc command with these mandatory parameters:
:aname=<association name>
:lhost = <local host name from the rtrv-ip-host output>
and with at least one of these optional parameters.
:lport = <local port ID>
:rhost = <remote host name>
:rport = <remote port ID>
:link = <the signaling link from the rtrv-slk output>
:adapter = m2pa
:alhost = <alternate local host name from the rtrv-ip-host output>
:m2patset = 1-20
(See Notes 1 through 11)
command with this parameter.
signaling link>
:aname=<association name>
to the card>
Enter the rept-stat-slk
command with these
parameters.
:loc = <card location of the IP
signaling link>
:link = <signaling link
assigned to the card>
IETF M2PA Configuration Procedures
Is the
No
association to be
activated?
Enter the rtrv-assoc
chg-db:action=backup:dest=fixed
Yes
Enter the chg-assoc
command with these
parameters.
:aname=<association
name>
:open=yes
:alw=yes
Enter the
command.
147
