Database Administration Manual - IP7 Secure
Gateway
Sheet 5 of 5

Figure 93: Adding an IPSG M3UA Linkset

910-6278-001 Revision A, January 2012
From
Sheets 2,
3, or 4
Add the IPSG M3UA linkset with the ent-ls command and
these mandatory parameters:
:lsn = <linkset name, not shown in the rtrv-ls output>
:apc/apca/apci/apcn/apcn24 = <adjacent point code shown in
the rtrv-dstn output, but not shown in the rtrv-sid output>
:lst = a
:ipsg = yes
:adapter = m3ua
:maxslktps = <100 - 5000>
:rsvdslktps = <0 - 5000>
and with any of these optional parameters.
:rcontext = < 0 4294967295> Default value = no value specified
:asnotif = < yes, no> Default value = yes
:tpsalmtype = <rsvdslktps, maxslktps> Default value = rsvdslktps
:lsusealm = <10 - 100> Default value = 100
:slkusealm = <10 - 100> Default value = 80
Notes:
1. The maxslktps parameter value must be greater than or equal to the
rsvdslktps parameter value.
2. The slktps parameter can be used in place of the rsvdslktps parameter.
There are other optional parameters that can be specified with the ent-ls
command. See the Other Optional Parameters" section in the Adding
an IPSG M3UA Linkset" Procedure in the Database Administration
Manual IP7 Secure Gateway for the procedures that discuss these
parameters and their usage.
Enter the rtrv-ls command
with this parameter.
:lsn=<linkset name specified
in the ent-ls command>
Enter the
chg-db:action=backup:dest=fixed
command
IPSG M2PA and M3UA Configuration Procedures
690
