Database Administration Manual - IP7 Secure
Gateway
If the IPSG value of the linkset is yes, and the ADAPTER value is m2pa, continue the procedure by
performing one of these actions.
If a new IPSG card was added in
If the signaling link will be assigned to an existing IPSG card, the RSVDSLKTPS value that is
assigned to the linkset will be assigned to the signaling link. The sum of the TPS used by all the
signaling links that are assigned to the IPSG card cannot exceed 5000 TPS. The TPS used by the
IPSG card and the TPS used by each signaling link that is assigned to the IPSG card is shown
by entering the rtrv-slk command with the location of the IPSG card. If the 5000 TPS limit
for the IPSG card will be exceeded by adding the IPSG M2PA signaling link, one of these actions
must be performed.
Another IPSG card must be used for the IPSG M2PA signaling link. Repeat this procedure
from Step
The RSVDSLKTPS values for the linksets shown in the rtrv-slk output for the IPSG card,
shown in
Perform these procedures as necessary to change the RSVDSLKTPS values for the linksets.
After the linksets have been changed, continue the procedure with
Changing an IPSG M2PA Linkset
Changing an IPSG M3UA Linkset
7. Display the total provisioned system TPS by entering the rtrv-tps command. This is an example
of the possible output.
rlghncxa03w 10-07-10 16:20:46 GMT
CARD NUM
TYPE CARDS
----- -----
IPGW 17
IPSG 4
IPLIM 2
ATM 2
Total provisioned System TPS (103668 of 500000) 21%
Command Completed.
An IPSG M2PA signaling link uses can use as much as 5000 TPS, as provisioned by the rsvdslktps
parameter of the linkset that the IPSG M2PA signaling link will be added to. If adding the new
IPSG M2PA signaling link will not exceed the maximum total provisioned system TPS, continue
the procedure with
If adding the new IPSG M2PA signaling link will exceed the maximum total provisioned system
TPS, and the maximum total provisioned system TPS is 500,000 shown, perform the "Activating
the HIPR2 High Rate Mode Feature" procedure in the Database Administration Manual - System
Management to enable and turn on the HIPR2 High Rate Mode feature. When the HIPR2 High Rate
Mode feature is enabled and turned on, the maximum total provisioned system TPS is increased
to 750,000. After the HIPR2 High Rate Mode feature has been enabled and turned on, continue the
procedure with
If the maximum total provisioned system TPS is 750,000, or the maximum total provisioned system
TPS is 500,000 and will not be increased, and adding the IPSG M2PA signaling link will exceed the
maximum total provisioned system TPS, the IPSG M2PA signaling link cannot be added unless
910-6278-001 Revision A, January 2012
Step
3.
Step 4, must be reduced enough to allow the IPSG M2PA linkset to be added.
NUM RSVD
LINKS TPS
----- -------- --------
16 48000
8 4700
4 8000
2 3668
Step 11.
Step 11.
IPSG M2PA and M3UA Configuration Procedures
3, continue the procedure with
EAGLE 42.0.0
MAX
TPS
80000
12000
8000
3668
Step 7.
Step 7.
