Database Administration Manual - IP7 Secure
Gateway
LOC LINK LSN
1101 A2 lssg1101
IPTPS for LOC = 1101 is (1000 of 5000) 20%
rtrv-slk:loc=1105
This is an example of the possible output.
rlghncxa03w 08-04-24 14:02:40 EST
rtrv-slk:loc=1101
Command entered at terminal #4.
LOC LINK LSN
1105 A7 lssg1101
IPTPS for LOC = 1105 is (1000 of 5000) 20%
If the new RSVDSLKTPS value for the linkset will allow the TPS for the IPSG cards containing the
IPSG signaling links in the linkset to exceed 5000, choose an RSVDSLKTPS value that will not exceed
the 5000 TPS limit for the IPSG card.
5. Display the total provisioned system TPS by entering the rtrv-tps command. This is an example
of the possible output.
rlghncxa03w 10-07-10 16:20:46 GMT
CARD NUM
TYPE CARDS
----- -----
IPGW 17
IPSG 3
IPLIM 2
ATM 2
Total provisioned System TPS (99668 of 500000) 20%
Command Completed.
An IPSG M2PA linkset uses 100 to 5000 TPS, as provisioned by the maxslktps parameter. If adding
the new IPSG M2PA linkset will not exceed the maximum total provisioned system TPS, continue
the procedure with
If adding the new IPSG M2PA linkset will exceed the maximum total provisioned system TPS, and
the maximum total provisioned system TPS is 500,000 shown, perform the "Activating the HIPR2
High Rate Mode Feature" procedure in the Database Administration Manual - System Management to
enable and turn on the HIPR2 High Rate Mode feature. When the HIPR2 High Rate Mode feature
is enabled and turned on, the maximum total provisioned system TPS is increased to 750,000. After
the HIPR2 High Rate Mode feature has been enabled and turned on, continue the procedure with
Step 11.
If the maximum total provisioned system TPS is 750,000, or the maximum total provisioned system
TPS is 500,000 and will not be increased, and adding the IPSG M2PA linkset will exceed the
maximum total provisioned system TPS, the IPSG M2PA linkset cannot be added unless the amount
of available TPS is reduced enough to allow the IPSG M2PA linkset to be changed. The available
TPS can be increased by performing one or more of these actions.
The IP TPS values of some IPGWx linksets have to be changed. To perform this action, continue
the procedure with
910-6278-001 Revision A, January 2012
SLC TYPE
0 IPSG
SLC TYPE
0 IPSG
NUM RSVD
LINKS TPS
----- -------- --------
16 48000
7 4200
4 8000
2 3668
Step 11.
Step 8.
IPSG M2PA and M3UA Configuration Procedures
ANAME SLKTPS
m2pa2 1000
38.0.0
ANAME SLKTPS
m2pa2 1000
EAGLE 42.0.0
MAX
TPS
80000
8000
8000
3668
