Database Administration Manual - IP7 Secure
Gateway
If the signaling link will be assigned to an existing IPSG card, the RSVDSLKTPS value that is
assigned to the linkset will be assigned to the signaling link. The sum of the TPS used by all the
signaling links that are assigned to the IPSG card cannot exceed 5000 TPS. The TPS used by the
IPSG card and the TPS used by each signaling link that is assigned to the IPSG card is shown
by entering the rtrv-slk command with the location of the IPSG card. If the 5000 TPS limit
for the IPSG card will be exceeded by adding the IPSG M2PA signaling link, one of these actions
must be performed.
Another IPSG card must be used for the IPSG M2PA signaling link. Repeat this procedure
from Step
The RSVDSLKTPS values for the linksets shown in the rtrv-slk output for the IPSG card,
shown in
Perform these procedures as necessary to change the RSVDSLKTPS values for the linksets.
After the linksets have been changed, continue the procedure with
Changing an IPSG M2PA Linkset
Changing an IPSG M3UA Linkset
6. Display the linkset that the signaling link is being assigned to using the rtrv-ls command,
specifying the name of the linkset that the signaling link is being assigned to.
For this example, enter this command.
rtrv-ls:lsn=lsipgw
This is an example of the possible output.
rlghncxa03w 10-07-17 11:43:04 GMT EAGLE5 42.0.0
LSN
lsipgw
---------------- -----------
SLSRSB RANDSLS ITUTFR
1
IPSG
yes
ADAPTER
m2pa
TPSALM
rsvdslktps 100%
LOC
1317 A
Link set table is (13 of 1024) 1% full.
If the IPSG value of the linkset is no, choose another linkset and repeat this procedure from
5.
If the IPSG value of the linkset is yes and the ADAPTER value is m3ua, choose another linkset and
repeat this procedure from
910-6278-001 Revision A, January 2012
3.
Step 4, must be reduced enough to allow the IPSG M2PA linkset to be added.
APCN (SS7) SCRN
2968 none
SPCN CLLI
off off
IPGWAPC GTTMODE
no CdPA
RSVDSLKTPS
500
LSUSEALM
LINK SLC TYPE
0 IPSG
Step 5.
IPSG M2PA and M3UA Configuration Procedures
L3T SLT
SET SET BEI LST LNKS ACT MES DIS SLSCI NIS
1 1 no A 1
TFATCABMLQ MTPRSE ASL8
1
CGGTMOD
no
MAXSLKTPS
4000
SLKUSEALM
100%
ANAME
m2pa2
Step 7.
GWS GWS GWS
off off off ---
--- ---
off
Step
