Database Administration Manual - IP7 Secure
Gateway
the amount of available TPS is reduced enough to allow the IPSG M2PA signaling link to be added.
The available TPS can be increased by performing one or more of these actions.
Some ATM high-speed signaling links have to be removed. To perform this action, continue
the procedure with
An IPLIMx card that contains signaling links has to be removed. To perform this action, continue
the procedure with
The IP TPS values of some IPGWx linksets have to be changed or the MAXSLKTPS values of
some IPSG linksets (and the RSVDSLKTPS values if necessary) have to be changed.
If linksets are displayed in the rept-stat-iptps output in
with Step 10.
If linksets are not displayed in the rept-stat-iptps output in
of these actions to increase the available TPS.
Note: If one or more of these actions are not performed to increase the available TPS and the
available TPS will not allow the IPSG M2PA signaling link to be added, the IPSG M2PA signaling
link cannot be added and the remainder of this procedure cannot be performed.
An IPLIMx card that contains signaling links has to be removed. To perform this action,
continue the procedure with
Some ATM high-speed signaling links have to be removed. To perform this action, continue
the procedure with
8. Display the ATM high-speed signaling links by entering this command.
rtrv-slk:type=saal
This is an example of the possible output.
rlghncxa03w 10-07-19 21:16:37 GMT EAGLE5 42.0.0
LOC LINK LSN
1303 A lsnds0
LOC LINK LSN
1306 A lsnituatm
SLK table is (30 of 1200) 2% full.
If ATM high-speed signaling links are shown in the rtrv-slk output, perform the "Removing an
SS7 Signaling Link" procedure in the Database Administration Manual - SS7 to remove some of the
ATM high-speed signaling links.
If ATM high-speed signaling links are not displayed in the rtrv-slk output, perform one or more
of these actions to increase the available TPS.
Note: If one or more of these actions are not performed to increase the available TPS and the
available TPS will not allow the IPSG M2PA signaling link to be added, the IPSG M2PA signaling
link cannot be added and the remainder of this procedure cannot be performed.
An IPLIMx card that contains signaling links has to be removed. To perform this action, continue
the procedure with
The IP TPS values of some IPGWx linksets have to be changed or the MAXSLKTPS values of
some IPSG linksets (and the RSVDSLKTPS values if necessary) have to be changed.
910-6278-001 Revision A, January 2012
IPSG M2PA and M3UA Configuration Procedures
Step 8.
Step 9.
Step 9.
Step 8.
LP
SLC TYPE SET BPS
1 LIMATM 1
LP
SLC TYPE SET BPS
0 LIME1ATM 21
Step 9.
Step
Step
ATM
TSEL VCI
1.544M LINE 5
ATM
TSEL VCI
2.048M LINE 5
5, continue the procedure
5, perform one or more
VPI LL
0 0
E1ATM
VPI CRC4 SI SN
0 ON 3 0
