Database Administration Manual - IP7 Secure
Gateway
From
Sheet 1
The new RSVDSLKTPS value for the
linkset cannot allow the sum of the TPS
used by all the IPSG signaling links that
are assigned to each IPSG card shown
in the linkset to exceed 5000 and cannot
exceed the maximum total provisioned
system TPS.
The new MAXSLKTPS value for the
linkset cannot exceed the maximum total
provisioned system TPS.
Enter the
rtrv-slk command with this
parameter.
:loc=<IPSG card location>
Repeat this step for each card
shown in the individual linkset,
the linkset that is being
changed, that was displayed on
this sheet.
Will the new
RSVDSLKTPS value exceed
the maximum 5000 TPS limit
for the card?
Yes
Choose another value for the
RSVDSLKTPS value that will
not exceed the maximum
5000 TPS limit for the card.
Sheet 2 of 8
910-6278-001 Revision A, January 2012
No
Do you wish
to change the maximum
total provisioned system
TPS value?
Perform the Activating the
HIPR2 High Rate Mode Feature"
procedure to enable and turn on
the HIPR2 High Rate Mode
To
feature. When the HIPR2 High
Sheet 5
Rate Mode feature is enabled
and turned on, the maximum
total provisioned system TPS
value is increased to 750,000.
IPSG M2PA and M3UA Configuration Procedures
Enter the rtrv-tps
command.
Will the
RSVDSLKTPS or the
MAXSLKTPS values exceed the
maximum total provisioned
system TPS?
Yes
What is
the maximum total
provisioned system TPS
value? See
the Note.
500,000
To add the signaling link , one or more
of these actions must be performed.
The IP TPS values of some IPGWx
linksets will have to be changed.
The MAXSLKTPS values of some
IPSG linksets (and the RSVDSLKTPS
values if necessary) will have to be
changed.
No
Some ATM high -speed signaling links
will have to be removed. An ANSI
ATM high -speed signaling link uses
1630 TPS. An ITU ATM high -speed
signaling link uses 2038 TPS.
Yes
Remove an IPLIMx card that contains
signaling links. An IPLIMx card that
contains signaling links uses 4000
TPS.
Note: The maximum total
provisioned system TPS
cannot be increased
beyond 750,000 TPS.
No
To
Sheet 5
750,000
To
Sheet 3
