Database Administration Manual - IP7 Secure
Gateway
DESTINATION ENTRIES ALLOCATED:
FULL DPC(s):
EXCEPTION DPC(s):
NETWORK DPC(s):
CLUSTER DPC(s):
TOTAL DPC(s):
CAPACITY (% FULL):
ALIASES ALLOCATED:
ALIASES USED:
CAPACITY (% FULL):
X-LIST ENTRIES ALLOCATED:
If the linkset being removed in this procedure is not assigned to a route exception table entry, no
entries are displayed in the rtrv-rtx output, but a summary of the point code quanties is
displayed.
If the name of the linkset being removed in this procedure shown in the LSN column in this step,
perform one of these procedures:
a) Change the name of the linkset in the entries displayed in this step by performing the "Changing
a Route Exception Entry" procedure in the Database Administration Manual - SS7.
b) Remove all the entries displayed in this step by performing the "Removing a Route Exception
Entry" procedure in the Database Administration Manual - SS7.
8. Verify whether or not the Flexible Linkset Optional Based Routing feature is enabled and turned
on by entering this command.
rtrv-ctrl-feat:partnum=893027701
This is an example of the possible output.
rlghncxa03w 09-05-10 11:43:04 GMT EAGLE5 41.0.0
The following features have been permanently enabled:
Feature Name
Flex Lset Optnl Based Rtg 893027701 on
The following features have been temporarily enabled:
Feature Name
Zero entries found.
The following features have expired temporary keys:
Feature Name
Zero entries found.
If the Flexible Linkset Optional Based Routing feature is enabled and turned on, continue the
procedure with
If the Flexible Linkset Optional Based Routing feature is not enabled or not turned on, continue
the procedure with
9. Display the GTT selectors that contain the linkset that is being removed by entering the
rtrv-gttsel command with the name of the linkset. For this example, enter this command.
rtrv-gttsel:lsn=ls1
910-6278-001 Revision A, January 2012
Partnum
Partnum
Partnum
Step 9.
Step 10.
IPSG M2PA and M3UA Configuration Procedures
2000
15
5
0
1
21
1%
12000
0
0%
500
Status Quantity
----
Status Quantity Trial Period Left
