9. Verify the values of the M2PA timer set you wish to assign to the association by entering the
rtrv-m2pa-tset command with the M2PA version (either ver=rfc to display the RFC M2PA
timer values or ver=d6 to display the Draft 6 M2PA timer values) of the timer set you wish to
assign to the association.
If the ver parameter is not specified with the rtrv-m2pa-tset command, both the RFC and
Draft 6 timer values are displayed.
To display the M2PA Draft 6 timer values, enter this command.
rtrv-m2pa-tset:ver=d6
This is an example of the possible output.
rlghncxa03w 06-10-28 21:16:37 GMT EAGLE5 36.0.0
M2PA Draft 6 Timers (in msec, T16 in microsec)
TSET T1
1 6000
2 7500
3 100000 ------ 2000
4 200000 ------ 20000 4000
5 250000 ------ 30000 30000 500
6 50000
7 10000
8 80000
9 27500
10 90000
11 20000
12 30000
13 40000
14 70000
15 9000
16 75000
17 350000 ------ 60000 70000 600
18 150000 ------ 55000 35000 500
19 175000 ------ 12500 45000 500
20 1000
To display the M2PA RFC values, enter this command.
rtrv-m2pa-tset:ver=rfc
This is an example of the possible output.
rlghncxa03w 06-10-28 21:16:37 GMT EAGLE5 36.0.0
M2PA RFC Timers (in msec, T16 in microsec)
TSET T1
1 6000
2 7500
3 100000 10000
4 200000 6000
5 250000 140000 30000 30000 500
6 50000
7 300000 20000
8 80000
9 27500
10 90000
11 20000
12 30000
910-6278-001 Revision A, January 2012
T2 T3 T4N
------ 5000 20000 500
------ 1500 2000
3000
------ 50000 60000 500
------ 10000 10000 500
------ 1500 15000 500
------ 3850 4859
------ 2500 50000 500
------ 4500 5500
------ 7500 7000
------ 35000 9000
------ 45000 11000 500
------ 25000 40000 500
------ 15000 25000 500
------ 1000 1000
T2 T3 T4N
75000 5000 20000 500
8000 1500 2000
2000 3000
20000 4000
100000 50000 60000 500
2000 10000 500
130000 1500 15000 500
120000 3850 4859
9000 2500 50000 500
60000 4500 5500
50000 7500 7000
IPSG M2PA and M3UA Configuration Procedures
T4E T5 T6 T7
5000 4000 1000
500 9000 1250 300
500 4000 1500 500
500 6000 2000 700
100 2250 400
500 4500 800
1000 3000 1200
8000 2750 1100
450 5700 3750 1150
7500 5000 1750
500 6500 5500 1600
500 750 4250 1800
500 1250 3500 1900
1500 1750 900
2500 3250 600
4500 1600 1400
10000 6000 2000
3500 5750 1500
1100 2600 1300
400 80 1000 200
T4E T5 T6 T7
5000 4000 1000
500 9000 1250 300
500 4000 1500 500
500 6000 2000 700
100 2250 400
500 4500 800
1000 3000 1200
8000 2750 1100
450 5700 3750 1150
7500 5000 1750
500 6500 5500 1600
500 750 4250 1800
T16 T17 T18
100000 150 500
150000 175 600
170000 200 800
480000 225 900
400000 400 8000
300000 300 7000
200000 250 1000
350000 350 5000
250 375 8750
440000 450 3000
250000 475 4500
275000 275 3500
500 325 9000
1000 125 6000
5000 425 5500
6000 240 9500
500000 500 10000
125000 440 750
7000 340 850
100 100 100
T16 T17 T18
100000 150 500
150000 175 600
170000 200 800
480000 225 900
400000 400 8000
300000 300 7000
200000 250 1000
350000 350 5000
250 375 8750
440000 450 3000
250000 475 4500
275000 275 3500
