Database Administration Manual - IP7 Secure
Gateway
CHG-LS: MASP A - COMPLTD
5. The new RSVDSLKTPS value for the linkset cannot allow the sum of the TPS used by all the IPSG
signaling links that are assigned to each IPSG card shown in the linkset to exceed 5000 and cannot
exceed the maximum total provisioned system TPS.
To verify the TPS for the IPSG cards containing the IPSG signaling links in the linkset, enter the
rtrv-slk command with the card location of each signaling link that is assigned to the linkset.
For this example, enter these commands.
rtrv-slk:loc=1101
This is an example of the possible output.
rlghncxa03w 08-04-24 14:02:40 EST
LOC LINK LSN
1101 A2 lssg1101
IPTPS for LOC = 1101 is (1000 of 5000) 20%
rtrv-slk:loc=1105
This is an example of the possible output.
rlghncxa03w 08-04-24 14:02:40 EST
LOC LINK LSN
1105 A7 lssg1101
IPTPS for LOC = 1105 is (1000 of 5000) 20%
If the new RSVDSLKTPS value for the linkset will allow the TPS for the IPSG cards containing the
IPSG signaling links in the linkset to exceed 5000, choose an RSVDSLKTPS value that will not exceed
the 5000 TPS limit for the IPSG card.
6. Display the total provisioned system TPS by entering the rtrv-tps command. This is an example
of the possible output.
rlghncxa03w 10-07-10 16:20:46 GMT
CARD NUM
TYPE CARDS
----- -----
IPGW 17
IPSG 3
IPLIM 2
ATM 2
Total provisioned System TPS (99668 of 500000) 20%
Command Completed.
An IPSG M3UA linkset uses 100 to 5000 TPS, as provisioned by the maxslktps parameter. If
adding the new IPSG M3UA linkset will not exceed the maximum total provisioned system TPS,
continue the procedure with
If adding the new IPSG M3UA linkset will exceed the maximum total provisioned system TPS,
and the maximum total provisioned system TPS is 500,000 shown, perform the "Activating the
HIPR2 High Rate Mode Feature" procedure in the Database Administration Manual - System
910-6278-001 Revision A, January 2012
SLC TYPE
0 IPSG
SLC TYPE
0 IPSG
NUM RSVD
LINKS TPS
----- -------- --------
16 48000
7 4200
4 8000
2 3668
Step 12.
IPSG M2PA and M3UA Configuration Procedures
38.0.0
ANAME SLKTPS
m3ua2 1000
38.0.0
ANAME SLKTPS
m3ua3 1000
EAGLE 42.0.0
MAX
TPS
80000
8000
8000
3668
