Database Administration Manual - IP7 Secure
Gateway
Enter the
rtrv-ip-rte command
Perform the "Adding an
IPSG Card" procedure in
this chapter to add the
required IP card to the
database
Perform the "Changing an IP Card"
procedure in this chapter and make
sure that the network portion of the
IP addresses assigned for the A or
B interfaces is the same as the
network portion of the IP address
that will be assigned to the gtwy
parameter of the IP route
Choose values for the dest and
submask parameters of the
ent-ip-rte command that do not
produce the same subnet address as
these parameter values shown in the
rtrv-netopts output.
PVN and PVNMASK
FCNA and FCNAMASK
FCNB and FCNBMASK
The subnet address resulting from
the dest and submask parameter
values of the ent-ip-rte command
cannot be the same as the subnet
address resulting from the PVN and
PVNMASK, FCNA and FCNAMASK,
or FCNB and FCNBMASK values
shown in the rtrv-netopts output.
Sheet 1 of 2
910-6278-001 Revision A, January 2012
IPSG M2PA and M3UA Configuration Procedures
Enter the
rtrv-ip-card command
Is the required
No
IP card in the
database?
Yes
Is a Class B IP
address to be specified
as the value for the dest
parameter in the ent-ip-rte
command?
Yes
Enter the
rtrv-netopts command
No
Is error message
E3967 displayed?
Yes
To
Sheet 2
No
