Database Administration Manual - IP7 Secure
Gateway
Specifying the lhost parameter only creates a uni-homed endpoint. The network portion of
the endpoint's IP address must be the same as the network portion of the IP address assigned
to either the A or B network interface of the IP card.
Specifying the lhost and alhost parameters creates a multi-homed endpoint. The network
portion of the IP address associated with the lhost parameter must be the same as the network
portion of the IP address assigned to one of the network interfaces (A or B) of the IP card, and
the network portion of the IP address associated with the alhost parameter must be the same
as the network portion of the IP address assigned to the other network interface on the IP card.
The alhost=none parameter removes the alternate local host from the specified association,
which also removes the multi-homed endpoint capability.
The m2patset and ver parameters can be specified only for IPSG M2PA associations.
If the mp2atset parameter is not specified with the chg-assoc command, and the adapter
parameter value is being changed to m2pa, the m2patset parameter value defaults to M2PA
timer set 1 (m2patset=1).
The M2PA version of the association determines the version of the M2PA timer set that is
assigned to the association. For example, if M2PA timer set 3 is assigned to the M2PA association,
and the association is an RFC M2PA association, the RFC version of M2PA timer set 3 is used
with the association. If M2PA timer set 7 is assigned to the M2PA association, and the association
is a Draft 6 M2PA association, the Draft 6 version of M2PA timer set 7 is used with the association.
If the adapter parameter value of the association is changed to m2pa in this procedure and
the ver parameter is not specified, the version of the association will be RFC. To make this
association a M2PA Draft 6 association, the ver=d6 parameter must be specified for this
association.
When this command has successfully completed, this message should appear.
rlghncxa03w 08-04-28 09:12:36 GMT EAGLE5 38.0.0
CHG-ASSOC: MASP A - COMPLTD;
Continue the procedure by performing one of these steps.
If the association was not assigned to a signaling link when this procedure was started, and the
open parameter value was not changed in
If the association was not assigned to a signaling link when this procedure was started, and the
open parameter value was changed in
If the association was assigned to a signaling link when this procedure was started, continue
the procedure with
12. Assign the association to a signaling link by performing one of these procedures.
If the ADAPTER value of the association is M2PA, perform the
procedure.
If the ADAPTER value of the association is M3UA, perform the
Link procedure.
After the association has been assigned to a signaling link, continue the procedure with one of
these steps.
If the open parameter value was not changed in
If the open parameter value was changed in
13. Change the value of the open parameter to yes by specifying the chg-assoc command with the
open=yes parameter.
910-6278-001 Revision A, January 2012
IPSG M2PA and M3UA Configuration Procedures
Step
Step 12.
Step 3, continue the procedure with
3, continue the procedure with
Adding an IPSG M2PA Signaling Link
Adding an IPSG M3UA Signaling
Step 3, continue the procedure with
Step 3, continue the procedure with
Step 14.
Step 12.
Step 14.
Step 13
