:force – If the global title translation feature is on, the force=yes parameter allows the LIM to be
added to the database even if the current SCCP transactions-per-second threshold is unable to support
the additional SCCP transaction-per-second capacity created by adding the IP card. This parameter
is obsolete and is no longer used.
Card Slot Selection
The single-slot EDCM and E5-ENET card can be inserted into any card slot, except for card slots that
must remain empty to accommodate dual-slot cards, slots 09 and 10 in each shelf, and slots 1113
through 1118.
To provision a E5-ENET card, the shelf containing the E5-ENET card must have HIPR or HIPR2 cards
installed in slots 9 and 10 in that shelf. If HIPR or HIPR2 cards are not installed in the shelf that the
E5-ENET card will occupy, the E5-ENET card will be auto-inhibited when the E5-ENET card is inserted
into the shelf. Enter the rept-stat-gpl:gpl=hipr command to verify whether or not HIPR cards
are installed in the same shelf as the E5-ENET card being provisioned in this procedure. Enter the
rept-stat-gpl:gpl=hipr2 command to verify whether or not HIPR2 cards are installed in the
same shelf as the E5-ENET card being provisioned in this procedure.
Before adding an IPLIMx card, the Eagle 5 STP must have a fan unit, and the fan feature must be
turned on. Also, the MFC STP option must be on.
1. Display the cards in the database using the rtrv-card command.
This is an example of the possible output. Cards should be distributed throughout the EAGLE 5
ISS for proper power distribution. Refer to the Installation Manual - EAGLE 5 ISS for the shelf power
distribution.
rlghncxa03w 09-05-05 08:12:53 GMT
CARD TYPE
1101 DSM
1102 TSM
1113 GSPM
1114 TDM-A
1115 GSPM
1116 TDM-B
1117 MDAL
1201 LIMDS0
1203 LIMDS0
1204 LIMDS0
1206 LIMDS0
1216 DCM
1301 LIMDS0
1302 LIMDS0
1303 DCM
1305 DCM
1307 DCM
2101 ENET
2103 ENET
2105 ENET
2107 ENET
2201 DCM
2203 DCM
2207 DCM
2211 DCM
2213 DCM
2215 DCM
2217 DCM
2301 DCM
2303 DCM
2305 DCM
2307 DCM
910-6278-001 Revision A, January 2012
41.0.0
APPL LSET NAME
VSCCP
GLS
EOAM
EOAM
SS7ANSI sp2
SS7ANSI sp3
SS7ANSI sp3
SS7ANSI nsp3
STPLAN
SS7ANSI sp6
SS7ANSI sp7
IPLIM ipnode1
IPLIM ipnode4
STPLAN
IPSG
IPSG
IPSG
IPSG
IPLIM
IPLIM
IPLIM
SS7IPGW
SS7IPGW
IPGWI
IPGWI
SS7IPGW
SS7IPGW
IPGWI
IPGWI
IETF M2PA Configuration Procedures
LINK SLC LSET NAME
A 0 sp1
A 0
A 1
A 1 nsp4
A 1 sp7
A 1 sp5
A 0 ipnode3
A 0
LINK SLC
B 0
B 1
B 0
B 1
B 1
