Configuring IPSG M3UA Linkset Options

This procedure is used to configure the options for an IPSG M3UA linkset with the chg-lsopts
command and these parameters.
:lsn - The name of the IPSG M3UA linkset.
:numslkalw - This parameter specifies the number of IS-NR (in-service normal) signaling links in
the IPSG M3UA linkset required to change the state of the linkset from the Restricted or Prohibited
state to the Allowed state. When the number of IS-NR signaling links in the linkset changes from a
value that is less than the numslkalw parameter value to a value that is equal or greater than the
numslkalw value, the state of the linkset changes to the Allowed state. The value of this parameter
is from 0 to 16. The value of this parameter cannot exceed the number of signaling links that are
assigned to the linkset. The value 0 represents half the number of signaling links that are assigned to
the linkset. If this parameter is not specified, the current value of this parameter is not changed. The
system default value for this parameter is 1.
:numslkrstr - This parameter specifies the number of signaling links in the IPSG M3UA linkset
required to change the state of the linkset from the Allowed state to the Restricted state. When the
number of IS-NR signaling links in the linkset changes from a value that is equal to or greater than
the numslkrstr parameter value to a value that is less than the numslkrstr parameter value and
greater than the numslkproh parameter value, the state of the linkset changes from the Allowed state
to the Restricted state. Changing the state of the linkset from the Prohibited state to the Restricted state
is not supported. The value of this parameter is from 0 to 16. The value of this parameter cannot exceed
the number of signaling links that are assigned to the linkset. The value 0 represents half the number
of signaling links that are assigned to the linkset. If this parameter is not specified, the current value
of this parameter is not changed. The system default value for this parameter is 1.
:numslkproh - This parameter specifies the number of signaling links in the IPSG M3UA linkset
required to change the state of the linkset from the Allowed or Restricted state to the Prohibited state.
When the number of IS-NR signaling links in the linkset changes from a value that is equal to or greater
than the numslkproh parameter value to a value that is less than the numslkproh parameter value,
the state of the linkset changes from the Allowed or Restricted state to the Prohibited state. The value
of this parameter is from 0 to 16. The value of this parameter cannot exceed the number of signaling
links that are assigned to the linkset. The value 0 represents half the number of signaling links that
are assigned to the linkset. If this parameter is not specified, the current value of this parameter is not
changed. The system default value for this parameter is 1.
An IPSG M3UA linkset is a linkset that contains these values: IPSG=yes, ADAPTER=m3ua.
If the IPSG M3UA linkset contains no signaling links, the value of the numslkalw, numslkrstr, or
numslkproh parameters can only be changed to 0 or 1.
If 0 is specified as the value of the numslkalw, numslkrstr, or numslkproh parameters, a number
with an asterisk (*) is shown as the value of the numslkalw, numslkrstr, or numslkproh parameter.
1. Display the IPSG and IPGWx linksets that are provisioned in the database by entering the
rept-stat-iptps command.
The following is an example of the possible output.
rlghncxa03w 10-07-19 21:16:37 GMT EAGLE5 42.0.0
IP TPS USAGE REPORT
