Database Administration Manual - IP7 Secure
Gateway
whose IPSG value is yes and ADAPTER value is M3UA) to change the MAXSLKTPS value (and
RSVDSLKTPS value if necessary) for any linksets shown in the rtrv-ls output.
Perform one or both of these actions to increase the available TPS if needed.
An IPLIMx card that contains signaling links has to be removed. To perform this action, continue
the procedure with
Some ATM high-speed signaling links have to be removed. To perform this action, continue
the procedure with
If you do not wish to perform other actions to increase the available TPS and the available TPS will
allow the IPSG M2PA linkset to be added, continue the procedure with
12. Add the new linkset to the database using the ent-ls command. The new linkset must meet these
conditions.
The name of this linkset cannot be used by another linkset – the linkset configuration is shown in
the output of
The APC of the new linkset must be in the destination point code table, but cannot be either the
EAGLE 5 ISS's point code or the EAGLE 5 ISS's capability point code – shown in the outputs of
Step 2, Step 3, and
:apc/apca – ANSI point code, ANSI private point code
:apci – ITU-I point code, ITU-I spare point code, ITU-I private point code, ITU-I private spare
point code.
:apcn – 14-bit ITU-N point code, 14-bit ITU-N spare point code, 14-bit ITU-N private point code,
14-bit ITU-N private spare point code.
:apcn24 – 24-bit ITU-N point code, 24-bit ITU-N private point code.
These parameters and values must also be specified for the IPSG M2PA linkset:
ipsg=yes
adapter=m2pa
lst=<a,b,c,d,e>
maxslktps=<100 - 5000>
rsvdslktps=<0 - 5000>
Note: The maxslktps parameter value must be greater than or equal to the rsvdslktps
parameter value. The slktps parameter can be used in place of the rsvdslktps parameter.
The ipgwapc, iptps, rcontext, and asnotif parameters cannot be specified for an IPSG
M2PA linkset.
These optional parameters can be specified with the ent-ls command.
lsusealm - the linkset's IP TPS alarm threshold. The default value for the lsusealm
parameter is 100.
slkusealm - the signaling link IP TPS alarm threshold. The default value for the slkusealm
parameter is 80.
tpsalmtype - The TPS threshold that will generate alarms, either rsvdslktps or
maxslktps. The default value for the tpsalmtype parameter is rsvdslktps.
For this example, enter this command.
910-6278-001 Revision A, January 2012
Step 9.
Step 8.
Step 1.
Step 4. The adjacent point code can be one of the following types of point codes:
IPSG M2PA and M3UA Configuration Procedures
Step 12.
