Database Administration Manual - IP7 Secure
Gateway
The EAGLE 5 ISS can contain a maximum of 4000 connections.
A maximum of 32 associations can be assigned to an IPSG card.
Before the local host value of the IPSG association can be changed, the signaling link that the association
is assigned to must be removed by performing one of these procedures.
If the ADAPTER value of the association is M2PA, perform the
Link procedure.
If the ADAPTER value of the association is M3UA, perform the
Link procedure.
Uni-homed endpoints are associations configured with the lhost parameter only. The lhost parameter
value represents an IP address that corresponds to either the A or B network interface of the IPSG
card. Multi-homed endpoints are associations configured with both the lhost and alhost parameters.
The lhost parameter value represents an IP address corresponding to one of the network interfaces
(A or B) of the IPSG card while the alhost parameter value represents an IPSG address corresponding
to the other network interface of the same IPSG card.
The alhost=none parameter removes the alternate local host from the specified association, which
also removes the multi-homed endpoint capability.
Canceling the RTRV-ASSOC Command
Because the rtrv-assoc command used in this procedure can output information for a long period
of time, the rtrv-assoc command can be canceled and the output to the terminal stopped. There
are three ways that the rtrv-assoc command can be canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-assoc command was
entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-assoc command
was entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rtrv-assoc command
was entered, from another terminal other that the terminal where the rtrv-assoc command was
entered. To enter the canc-cmd:trm=<xx> command, the terminal must allow Security
Administration commands to be entered from it and the user must be allowed to enter Security
Administration commands. The terminal's permissions can be verified with the rtrv-secu-trm
command. The user's permissions can be verified with the rtrv-user or rtrv-secu-user
commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the associations in the database using the rtrv-assoc command.
This is an example of possible output.
rlghncxa03w 08-04-28 09:12:36 GMT EAGLE5 38.0.0
ANAME
swbel32
a2
a3
assoc1
assoc2
assoc3
assoc5
910-6278-001 Revision A, January 2012
CARD IPLNK
LOC PORT LINK ADAPTER LPORT RPORT OPEN ALW
1201 A A M3UA
1305 A A SUA
1307 A A SUA
1201 A A M3UA
2105 A A M2PA
2105 A B2 M2PA
2105 A A3 M2PA
IPSG M2PA and M3UA Configuration Procedures
Removing an IPSG M2PA Signaling
Removing an IPSG M3UA Signaling
1030 2345 YES
1030 2345 YES
1030 2346 YES
2000 1030 YES
2048 2048 YES
3000 3000 YES
1500 3000 YES
YES
YES
YES
YES
YES
YES
YES
