The dlt-ls command has only one parameter, lsn, which is the name of the linkset to be removed
from the database.
The linkset to be removed must exist in the database.
To remove a linkset, all links associated with the linkset must be removed.
The linkset to be removed cannot be referenced by a routeset.
If the Flexible Linkset Optional Based Routing feature is enabled and turned on, and the linkset is
referenced by a GTT selector, the linkset cannot be removed.
A proxy linkset whose APC is assigned to more than one proxy linkset cannot be removed if the linkset
contains the proxy point code (shown in the PPCA/PPCI/PPCN/PPCN24 field in the
rtrv-ls:apc/apca/apci/apcn/apcn24=<APC of the linkset> output) that is also assigned
to the APC of the linkset. The proxy point code assigned to the APC of the linkset is shown in the
rtrv-dstn:dpc/dpca/dpci/dpcn/dpcn24=<APC of the linkset> output. The linksets that
do not contain the proxy point code that is assigned to the APC of the linkset must be removed before
the linkset containing proxy point code that is assigned to the APC of the linkset can be removed.
Canceling the RTRV-LS Command
Because the rtrv-ls command used in this procedure can output information for a long period of
time, the rtrv-ls command can be canceled and the output to the terminal stopped. There are three
ways that the rtrv-ls command can be canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-ls command was
entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-ls command
was entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rtrv-ls command was
entered, from another terminal other that the terminal where the rtrv-ls command was entered.
To enter the canc-cmd:trm=<xx> command, the terminal must allow Security Administration
commands to be entered from it and the user must be allowed to enter Security Administration
commands. The terminal's permissions can be verified with the rtrv-secu-trm command. The
user's permissions can be verified with the rtrv-user or rtrv-secu-user commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the IPSG linksets by entering the rept-stat-iptps command. This is an example of the
possible output.
rlghncxa03w 10-07-19 21:16:37 GMT EAGLE5 42.0.0
IP TPS USAGE REPORT
THRESH
-------------------------------------------------------------------------
LSN
is1
-------------------------------------------------------------------------
Command Completed.
2. Display the linkset that will be removed by entering the rtrv-ls command with the name of the
linkset shown in
rtrv-ls:lsn=ls1
910-6278-001 Revision A, January 2012
CONFIG/ CONFIG/
RSVD
100% 500 2000
Step 1. This is an example of the possible output.
IPSG M2PA and M3UA Configuration Procedures
TPS PEAK
MAX
TX: 427 550
RCV: 312 450
PEAKTIMESTAMP
10-07-19 09:49:19
10-07-19 09:49:19
