Database Administration Manual - IP7 Secure
Gateway
4. Display the signaling links assigned to the IPSG card by entering the rtrv-slk command with
the card location of the IPSG card. For this example, enter this command.
rtrv-slk:loc=2204
This is an example of the possible output.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
LOC LINK LSN
2204 B lsnlp2
IPTPS for LOC = 2204 is ( 500 of 5000) 10%
An IPSG card can contain a maximum of 32 IPSG signaling links. If 32 signaling links are shown
in the rtrv-slk output, the new signaling link cannot be added to this card. Choose another IPSG
card and repeat this procedure from
If less than 32 signaling links are shown in the rtrv-slk output, continue the procedure by
performing one of these actions.
If the IPTPS value shown in the rtrv-slk output is less than 5000, continue the procedure
with Step 5.
If the IPTPS value shown in the rtrv-slk output is 5000, the new signaling link cannot be
added to this card. Choose another IPSG card and repeat this procedure from
5. Display the IPSG and IPGWx linksets by entering the rept-stat-iptps command.
This is an example of the possible output.
rlghncxa03w 10-07-19 21:16:37 GMT EAGLE5 42.0.0
IP TPS USAGE REPORT
THRESH
-------------------------------------------------------------------------
LSN
ipgwx1
ipgwx2
ipgwx3
ipsglsn
ipsglsn2
isipgw
-------------------------------------------------------------------------
Command Completed.
If the desired linkset is shown in the rept-stat-iptps output, continue the procedure with
6.
If the desired linkset is not shown in the rept-stat-iptps output, add the linkset by performing
the Adding an IPSG M2PA Linkset
If a new IPSG card was added in
910-6278-001 Revision A, January 2012
SLC TYPE
0 IPSG
Step
CONFIG/ CONFIG/
RSVD
100% ---- 32000
100% ---- 16000
100% ---- 32000
100% 600 24000
100% 600 4000
100% 500 4000
procedure. Continue the procedure with one of these actions.
Step
IPSG M2PA and M3UA Configuration Procedures
ANAME
m2pa
3.
TPS PEAK
MAX
TX: 3700 4000
RCV: 3650 4000
TX: 4800 5000
RCV: 4850 5000
TX: 427
RCV: 312
TX: 4800 5000
RCV: 4800 5000
TX: 427
RCV: 312
TX: 427
RCV: 312
3, continue the procedure with
SLKTPS
500
Step
PEAKTIMESTAMP
10-07-19 09:49:19
10-07-19 09:49:19
10-07-19 09:49:09
10-07-19 09:49:09
550 10-07-19 09:49:19
450 10-07-19 09:49:19
10-07-19 09:49:19
10-07-19 09:49:19
550 10-07-19 09:49:19
450 10-07-19 09:49:19
550 10-07-19 09:49:19
450 10-07-19 09:49:19
Step 7.
3.
Step
