ANSI ATM high-speed signaling links and a maximum or 368 ITU ATM high-speed signaling
links. For more information about configuring an ATM high-speed signaling link, see the
"Adding an ATM High-Speed Signaling Link procedure in the Database Administration Manual
- SS7 .
A maximum of 80 unchannelized E1 signaling links. An HC MIM can contain two unchannelized
E1 signaling links. An E5-E1T1 card can contain one unchannelized E1 signaling link.
A maximum of 180 unchannelized T1 signaling links. An unchannelized T1 signaling link can be
assigned only to an E5-E1T1 card. An E5-E1T1 card can contain one unchannelized T1 signaling
link.
The EAGLE 5 ISS can contain a maximum of 250 cards. This quantity does not include the control
cards. The sum of the quantities of the signaling links shown in this list cannot be provisioned in the
EAGLE 5 ISS as the EAGLE 5 ISS cannot contain enough cards to support the sum of the quantities
of these signaling links.
Other signaling links, not shown in this list, can be provisioned if there is space in the shelves for the
cards that support these signaling links, and the enabled signaling link quantity is not exceeded.
This hardware is the only hardware that is supported for an EAGLE 5 ISS containing 2001 to 2800
signaling links.
HC-MIM
E5-E1/T1
E5-ATM
E5-SM4G
E5-ENET
E5-based control cards
Single-Slot EDCM or E5-SLAN card for the STPLAN feature
Single-Slot EDCM or E5-STC card for the EAGLE 5 Integrated Monitoring Support feature

Enabling the Large System # Links Controlled Feature

This procedure is used to enable the Large System # Links controlled feature using the feature's part
number and a feature access key.
The feature access key for the Large System # Links controlled feature is based on the feature's part
number and the serial number of the EAGLE 5 ISS, making the feature access key site-specific.
This feature allows the EAGLE 5 ISS to contain a maximum of either 1500, 2000, or 2800 signaling
links.
The enable-ctrl-feat command enables the controlled feature by inputting the controlled feature's
access key and the controlled feature's part number with these parameters:
:fak – The feature access key provided by Tekelec. The feature access key contains 13 alphanumeric
characters and is not case sensitive.
:partnum – The Tekelec-issued part number associated with the signaling link quantity being enabled:
893005901 for the 1500 signaling link quantity
893005910 for the 2000 signaling link quantity.
893005911 for the 2800 signaling link quantity.
