Database Administration Manual - IP7 Secure
Gateway
Display the pvn, pvnmask, fcna, fcnamask, fcnb, and fcnbmask parameter values of the
chg-netopts command by entering the rtrv-netoptscommand.
If error message E3967 Cmd Rej: E5IS must be on is displayed after the rtrv-netopts
command is executed, the pvn, pvnmask, fcna, fcnamask, fcnb, and fcnbmask parameters
are not configured. Continue the procedure with
This is an example of the possible output if the E5IS feature is on.
rlghncxa03w 09-02-28 21:17:37 GMT EAGLE5 40.1.0
NETWORK OPTIONS
------------------
PVN = 128.20.30.40
PVNMASK = 255.255.192.0
FCNA = 170.120.50.0
FCNAMASK = 255.255.240.0
FCNB = 170.121.50.0
FCNBMASK = 255.255.254.0
Choose dest and submask parameter values for the IP route whose resulting subnet address is
not be the same as the subnet address resulting from the pvn and pvnmask, fcna and fcnamask,
or fcnb and fcnbmask parameter values of the chg-netopts command. Continue the procedure
Step 4.
with
4. Add the IP route to the database using the ent-ip-rte command.
For this example, enter this command.
ent-ip-rte:loc=1212:dest=132.10.175.20:submask=255.255.255.255
:gtwy=150.1.1.50
When this command has successfully completed, this message should appear.
rlghncxa03w 06-10-12 09:12:36 GMT EAGLE5 36.0.0
ENT-IP-RTE: MASP A - COMPLTD
5. Verify the changes using the rtrv-ip-rte command with the card location specified with the
ent-ip-rte command in
For this example, enter these commands.
rtrv-ip-rte:loc=1212
This is an example of the possible output.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
LOC DEST
1212 132.10.175.20
IP Route table is
6. Back up the new changes using the chg-db:action=backup:dest=fixed command.
These messages should appear, the active Maintenance and Administration Subsystem Processor
(MASP) appears first.
BACKUP (FIXED) : MASP A - Backup starts on active MASP.
BACKUP (FIXED) : MASP A - Backup on active MASP to fixed disk complete.
BACKUP (FIXED) : MASP A - Backup starts on standby MASP.
BACKUP (FIXED) : MASP A - Backup on standby MASP to fixed disk complete.
910-6278-001 Revision A, January 2012
IPSG M2PA and M3UA Configuration Procedures
Step 4.
SUBMASK
255.255.255.255
(6 of 1024) 1% full
Step 4.
GTWY
150.1.1.50
