Splitting the range of CIC values creates two routing keys. The CIC values in one routing key ranges
from the cics value of the original routing key to a value equal to one less than the split value. The
CIC values in the other routing key ranges from the split value to the cice value of the original
routing key. All other parameters in both routing keys remain the same as in the original routing key.
The range of CIC values cannot be split if the routing key contains a routing context parameter value.
Table 40: Routing Key Parameter Combinations for Splitting the Range of CIC Values in an Existing
Routing Key
SI=4 (TUP)
dpci/dpcn/dpcn24=<the
DPC assigned to the
routing key> (See Note
1)
si=4 (See Note 1)
opci/opcn/opcn24=<the
OPC assigned to the
routing key> (See Note
1)
cics=<the CICS value
assigned to the routing
key> (See Note 1)
cice=<the CICE value
assigned to the routing
key> (See Note 1)
type=full
split=<0 to 4095> (See
Note 2)
1. The values for these parameters must be entered exactly as shown in the rtrv-appl-rtkey
command output for the routing key being changed. However, text strings can be used in place of
some numerical service indicator values. See
these text strings. The text string must correspond to the numerical value shown in the routing key
being changed.
2. The split parameter value must be greater than the cics parameter value and less than the
cice parameter value.
910-6278-001 Revision A, January 2012
SI=5 (ISUP)
dpc/dpca=<the DPC
assigned to the routing
key> (See Note 1)
si=5 (See Note 1)
opc/opca=<the OPC
assigned to the routing
key> (See Note 1)
cics=<the CICS value
assigned to the routing
key> (See Note 1)
cice=<the CICE value
assigned to the routing
key> (See Note 1)
type=full
split=<0 to 16383> (See
Note 2)
Table 38: Service Indicator Text String Values
IETF M3UA and SUA Configuration Procedures
dpci/dpcn/dpcn24=<the
DPC assigned to the
routing key> (See Note
1)
si=5 (See Note 1)
opci/opcn/opcn24=<the
OPC assigned to the
routing key> (See Note
1)
cics=<the CICS value
assigned to the routing
key> (See Note 1)
cice=<the CICE value
assigned to the routing
key> (See Note 1)
type=full
split=<0 to 4095> (See
Note 2)
SI=13 (QBICC)
dpc/dpca/dpci/
dpcn/dpcn24=<the
DPC assigned to the
routing key> (See Note
1)
si=13 (See Note 1)
opc/opca/opci/
opcn/opcn24=<the
OPC assigned to the
routing key> (See Note
1)
cics=<the CICS value
assigned to the routing
key> (See Note 1)
cice=<the CICE value
assigned to the routing
key> (See Note 1)
type=full
split=<0 to 4294967295>
(See Note 2)
