Database Administration Manual - IP7 Secure
Gateway
M2PA associations (adapter=m2pa) cannot be assigned to application servers. Only M3UA
(adapter=m3ua) and SUA (adapter=sua) associations can be assigned to application servers. This
can be verified in the ADAPTER field in the rtrv-assoc output.
The application server recovery timer (the tr parameter of the chg-as command) for the application
server is set by default to 10 milliseconds when an application server is added. The traffic mode (the
mode parameter of the chg-as command) for the application server is set by default to LOADSHARE
when an application server is added. Perform the
these parameter values.
Canceling the RTRV-AS and RTRV-ASSOC Commands
Because the rtrv-as and rtrv-assoc commands used in this procedure can output information
for a long period of time, the rtrv-as and rtrv-assoc commands can be canceled and the output
to the terminal stopped. There are three ways that the rtrv-as and rtrv-assoc commands can be
canceled.
Press the F9 function key on the keyboard at the terminal where the rtrv-as or rtrv-assoc
commands were entered.
Enter the canc-cmd without the trm parameter at the terminal where the rtrv-as or rtrv-assoc
commands were entered.
Enter the canc-cmd:trm=<xx>, where <xx> is the terminal where the rtrv-as or rtrv-assoc
commands were entered, from another terminal other that the terminal where the rtrv-as or
rtrv-assoc commands were entered. To enter the canc-cmd:trm=<xx> command, the terminal
must allow Security Administration commands to be entered from it and the user must be allowed
to enter Security Administration commands. The terminal's permissions can be verified with the
rtrv-secu-trm command. The user's permissions can be verified with the rtrv-user or
rtrv-secu-user commands.
For more information about the canc-cmd command, go to the Commands Manual.
1. Display the application servers in the database using the rtrv-as command. This is an example
of possible output.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
AS Name
as1
as2
as3
AS table is (3 of 250) 1% full.
2. Display the associations in the database using the rtrv-assoc command. This is an example of
possible output.
rlghncxa03w 06-10-28 09:12:36 GMT EAGLE5 36.0.0
ANAME
swbel32
a2
a3
assoc1
assoc7
910-6278-001 Revision A, January 2012
Mode Tr ms
LOADSHARE 10
OVERRIDE 10
OVERRIDE 10
CARD IPLNK
LOC PORT LINK ADAPTER LPORT RPORT OPEN ALW
1201 A A M3UA
1305 A A SUA
1307 A A SUA
1305 A A SUA
1311 A A SUA
IETF M3UA and SUA Configuration Procedures
Changing an Application Server
Association Names
a2
a3
assoc1
assoc7
swbel32
1030 2345 YES
2000 2345 YES
3000 3000 YES
4000 1030 YES
2500 2000 YES
procedure to change
YES
YES
YES
YES
YES
